ATmega328PB
AVR® Microcontroller with Core Independent Peripherals
and PicoPower® Technology
Introduction
The picoPower
®
ATmega328PB is a low-power CMOS 8-bit microcontroller based on the AVR
®
enhanced
RISC architecture. By executing powerful instructions in a single clock cycle, the ATmega328PB achieves
throughputs close to 1 MIPS per MHz. This empowers system designers to optimize the device for power
consumption versus processing speed.
Features
High Performance, Low-Power AVR
®
8-bit Microcontroller Family
• Advanced RISC Architecture
– 131 Powerful Instructions
– Most Single Clock Cycle Execution
– 32 x 8 General Purpose Working Registers
– Fully Static Operation
– Up to 20 MIPS Throughput at 20 MHz
– On-Chip 2-Cycle Multiplier
• High Endurance Nonvolatile Memory Segments
– 32 KB of In-System Self-Programmable Flash program memory
– 1 KB EEPROM
– 2 KB Internal SRAM
– Write/Erase Cycles: 10,000 Flash/100,000 EEPROM
– Optional Boot Code Section with Independent Lock Bits
• In-System Programming by On-chip Boot Program
• True Read-While-Write Operation
– Programming Lock for Software Security
• Peripheral Features
– Peripheral Touch Controller (PTC)
• Capacitive Touch Buttons, Sliders, and Wheels
• 24 Self-Cap Channels and 144 Mutual Cap Channels
– Two 8-bit Timer/Counters with Separate Prescaler and Compare Mode
– Three 16-bit Timer/Counters with Separate Prescaler, Compare Mode, and Capture Mode
– Real-Time Counter with Separate Oscillator
– Ten PWM Channels
– 8-channel 10-bit ADC
© 2018 Microchip Technology Inc.
Datasheet Complete
DS40001906C-page 1
