2
AVR098
2580D-AVR-02/07
2 General porting considerations
To make the porting process as easy as possible, always refer to registers and bit
positions using their defined names. Avoid using absolute addresses and values. In
most cases, the register and bit names are unchanged from device to device. When
you are porting a design, it is more convenient to include the correct definition file for
the new device, rather than manually changing all your addresses and bit values. It is
also considered good programming practice to use named references instead of
absolute values. Some examples are shown below.
PORTE |= (1<<PORTE5); // Set pin 5 on port E high
DDR &= ~(1<<PORTE5); // Set pin 5 on port E as input
// Configure USI
USICR = (1<<USISIE)|(0<<USIOIE)|(1<<USIWM1)|(0<<USIWM0)|
(1<<USICS1)|(0<<USICS0)|(0<<USICLK)|(0<<USITC);
To avoid conflicts with added features and register functionality, never access
registers that are marked as reserved. Reserved bits should always be written to zero
if accessed. This ensures forward compatibility, and that added features will stay in
their default states if not used.
3 Register and bit names
In ATmega169 and ATmega329/649, some register bits are in different locations
within a register, but neither the registers nor the bits have different names, nor are
any bits relocated into other registers.
Table 3-1 shows the register bits that have
been moved.
Table 3-1
. Moved register bits.
Bit names
PCIE1 PCIE0 PCIF1 PCIF0
In ATmega169 the USART module is named USART, while in ATmega329/649 it is
called USART0. This has consequences for all USART register and bit names, and
depending on the compiler used this might have consequences when porting the
code.
Table 3-2 shows the register names for ATmega169 and ATmega329/649
Table 3-2
. USART register names
ATmega169
Register name
Atmega169
Bit names
ATmega329/649
Register name
ATmega329/649
Bit names
RXB[7:0] RXB0[7:0]
UDR
TXB[7:0]
UDR0
TXB0[7:0]
RXC RXC0
TXC TXC0
UDRE UDRE0
FE FE0
DOR DOR0
UPE UPE0
UCSRA
U2X
UCSR0A
U2X0
