BAT54CWT1G 产品设计图 - Fairchild（飞兆/仙童）
制造商:
Fairchild（飞兆/仙童）
分类:
二极管阵列
封装:
SOT-323
描述:
FAIRCHILD SEMICONDUCTOR BAT54CWT1G 快速/超快二极管, 双共阴极, 30 V, 200 mA, 800 mV, 5 ns, 600 mA
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
封装尺寸在P1
焊盘布局在P1
标记信息在P1P2
导航目录
BAT54CWT1G数据手册
Page:
of 2 Go
若手册格式错乱，请下载阅览PDF原文件
SC−70 (SOT−323)
CASE 419−04
ISSUE N
DATE 11 NOV 2008
SCALE 4:1
STYLE 3:
PIN 1. BASE
2. EMITTER
3. COLLECTOR
STYLE 4:
PIN 1. CATHODE
2. CATHODE
3. ANODE
STYLE 2:
PIN 1. ANODE
2. N.C.
3. CATHODE
STYLE 1:
CANCELLED
STYLE 5:
PIN 1. ANODE
2. ANODE
3. CATHODE
STYLE 6:
PIN 1. EMITTER
2. BASE
3. COLLECTOR
STYLE 7:
PIN 1. BASE
2. EMITTER
3. COLLECTOR
A
A2
D
e1
b
e
E
A1
c
L
3
12
NOTES:
1. DIMENSIONING AND TOLERANCING PER ANSI Y14.5M, 1982.
2. CONTROLLING DIMENSION: INCH.
0.05 (0.002)
STYLE 8:
PIN 1. GATE
2. SOURCE
3. DRAIN
STYLE 9:
PIN 1. ANODE
2. CATHODE
3. CATHODE-ANODE
STYLE 10:
PIN 1. CATHODE
2. ANODE
3. ANODE-CATHODE
1.9
0.075
0.65
0.025
0.65
0.025
0.9
0.035
0.7
0.028
ǒ
mm
inches
Ǔ
SCALE 10:1
XX MG
G
XX = Specific Device Code
M = Date Code
G = Pb−Free Package
GENERIC
MARKING DIAGRAM
*This information is generic. Please refer to
device data sheet for actual part marking.
Pb−Free indicator, “G” or microdot “ G”,
may or may not be present.
1
*For additional information on our Pb−Free strategy and soldering
details, please download the ON Semiconductor Soldering and
Mounting Techniques Reference Manual, SOLDERRM/D.
SOLDERING FOOTPRINT*
H
E
DIM
A
MIN NOM MAX MIN
MILLIMETERS
0.80 0.90 1.00 0.032
INCHES
A1 0.00 0.05 0.10 0.000
A2 0.70 REF
b 0.30 0.35 0.40 0.012
c 0.10 0.18 0.25 0.004
D 1.80 2.10 2.20 0.071
E 1.15 1.24 1.35 0.045
e 1.20 1.30 1.40 0.047
0.035 0.040
0.002 0.004
0.014 0.016
0.007 0.010
0.083 0.087
0.049 0.053
0.051 0.055
NOM MAX
L
2.00 2.10 2.40 0.079 0.083 0.095
H
E
e1
0.65 BSC
0.38
0.028 REF
0.026 BSC
0.015
0.20 0.56
0.008 0.022
MECHANICAL CASE OUTLINE
PACKAGE DIMENSIONS
http://onsemi.com
1
© Semiconductor Components Industries, LLC, 2002
October, 2002 − Rev. 0
Case Outline Number:
XXX
DOCUMENT NUMBER:
STATUS:
NEW STANDARD:
DESCRIPTION:
98ASB42819B
ON SEMICONDUCTOR STANDARD
SC−70 (SOT−323)
Electronic versions are uncontrolled except when
accessed directly from the Document Repository. Printed
versions are uncontrolled except when stamped
“CONTROLLED COPY” in red.
PAGE 1 OF 2
