DS30222 Rev. 3 - 2 2 of 3 BC847BS
Electrical Characteristics
@ T
A
= 25°C unless otherwise specified
Characteristic Symbol Min Typ Max Unit Test Condition
DC Current Gain (Note 2)
h
FE
200 — 450 —
V
CE
= 5.0V, I
C
= 2.0mA
Collector-Emitter Saturation Voltage (Note 2)
V
CE(SAT)
—
—
—
100
400
mV
I
C
= 10mA, I
B
= 0.5mA
I
C
= 100mA, I
B
= 5.0mA
Base-Emitter Saturation Voltage (Note 2)
V
BE(SAT)
— 755 — mV
I
C
= 10mA, I
B
= 0.5mA
Base-Emitter Voltage (Note 2)
V
BE
580 665 700 mV
V
CE
= 5.0V, I
C
= 2.0mA
Collector Cutoff Current (Note 2)
I
CBO
I
CBO
—
—
—
15
5.0
nA
µA
V
CB
= 30V, I
E
= 0
V
CB
= 30V, T
j
= 125°C
Emitter Cutoff Current (Note 2)
I
EBO
— — 100 nA
V
EB
= 5.0V, I
C
= 0
Gain Bandwidth Product
f
T
100 — — MHz
V
CE
= 5.0V, I
C
= 10mA,
f = 100MHz
Collector-Base Capacitance
C
CBO
—— 1.5 pF
V
CB
= 10V, f = 1.0MHz
Emitter-Base Capacitance
C
EBO
—11 — pF
V
EB
= 0.5V, f = 1.0MHz
Month Jan Feb March Apr May Jun Jul
Aug Sep Oct Nov Dec
Code 1234567
89 OND
Year 1998 1999 2000 2001 2002
2003 2004
Code JKLM N
PR
Date Code Key
K1F = Product Type Marking Code
YM = Date Code Marking
Y = Year ex: N = 2002
M = Month ex: 9 = September
K1F
K1F
YM
YM
Marking Information
Notes: 2. Short duration pulse test used to minimize self-heating effect.
3. For Packaging Details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Device
Packaging Shipping
BC847BS-7
SOT-363 3000/Tape & Reel
Ordering Information
(Note 3)
