2002 May 28 5
NXP Semiconductors Product data sheet
Voltage regulator diodes BZX284 series
Table 2 Per type BZX284-B/C27 to B/C75
T
j
= 25 °C unless otherwise specified.
BZX284-
Bxxx
Cxxx
WORKING VOLTAGE
V
Z
(V)
at I
Ztest
= 2 mA
DIFFERENTIAL RESISTANCE
r
dif
(Ω)
TEMP. COEFF.
S
Z
(mV/K)
at
I
Ztest
= 2 mA
DIODE CAP.
C
d
(pF)
at f
= 1 MHz;
V
R
= 0 V
NON-REPETITIVE PEAK
REVERSE CURRENT
I
ZSM
(A) at t
p
= 100 μs;
T
amb
= 25 °C
Tol. ±2% (B) Tol. ±5% (C) at I
Ztest
= 0.5 mA at I
Ztest
= 2 mA
MIN. MAX. MIN. MAX. TYP. MAX. TYP. MAX. TYP. MAX. MAX.
27 26.50 27.50 25.1 28.9 35 250 8 40 23.4 73 1.0
30 29.40 30.60 28.0 32.0 35 250 10 40 26.6 66 1.0
33 32.30 33.70 31.0 35.0 40 275 11 40 29.7 60 0.9
36 35.30 36.70 34.0 38.0 40 300 15 60 33.0 59 0.8
39 38.20 39.80 37.0 41.0 40 300 25 75 36.4 58 0.7
43 42.10 43.90 40.0 46.0 45 325 30 80 41.2 56 0.6
47 46.10 47.90 44.0 50.0 45 325 30 90 46.1 55 0.5
51 50.00 52.00 48.0 54.0 45 350 35 110 51.0 52 0.4
56 54.90 57.10 52.0 60.0 50 375 40 120 57.0 49 0.3
62 60.80 63.20 58.0 66.0 60 400 50 140 64.4 44 0.3
68 66.60 69.40 64.0 72.0 75 400 55 160 71.7 40 0.25
75 73.50 76.50 70.0 79.0 85 400 70 175 80.2 35 0.2
