© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com C1007_X8R_ULTRA_150C_SMD • 1/14/2013 1

One world. One KEMET

Benets

• -55°C to +150°C operating temperature range

• Pb-Free and RoHS Compliant

• EIA 0402, 0603, 0805, 1206, 1210, and 1812 case sizes

• DC voltage ratings of 25 V, 50 V, and 100 V

• Capacitance offerings ranging from 10 pF to 0.22 μF

• Available capacitance tolerances of ±1%, ±2%, ±5%,

• Non-polar device, minimizing installation concerns

• Offered in both commercial and automotive grades

• 100% pure matte tin-plated termination nish that allowing for

excellent solderability.

• SnPb plated termination nish option available upon request (5%

minimum)

KEMET’s Ultra-Stable X8R dielectric features a 150°C maximum

operating temperature, offering the latest in high temperature

dielectric technology and reliability for extreme temperature ap-

plications. It offers the same temperature capability as conven-

tional X8R, but without the capacitance loss due to applied DC

voltage. Ultra-Stable X8R exhibits no change in capacitance with

respect to voltage and boasts a minimal change in capacitance

with reference to ambient temperature. It is a suitable replace-

ment for higher capacitance and larger footprint devices that fail

to offer capacitance stability. Capacitance change with respect to

applications.

In addition to commercial grade, automotive grade devices are

available and meet the demanding Automotive Electronics Coun-

cil’s AEC–Q200 qualication requirements.

Surface Mount Multilayer Ceramic Chip Capacitors (SMD MLCCs)

High Temperature 150°C, Ultra-Stable X8R Dielectric,

Ordering Information

Failure Rate/

0603

0805

1206

1210
