C0603C683K5RACAUTO 其他数据使用手册 - KEMET Corporation（基美）
制造商:
KEMET Corporation（基美）
分类:
陶瓷电容
封装:
0603
描述:
KEMET C0603C683K5RACAUTO 多层陶瓷电容器, 表面贴装, AEC-Q200 C Series, 0.068 µF, ± 10%, X7R, 50 V, 0603 [1608 公制]
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
标记信息在P1
封装信息在P1
技术参数、封装参数在P1
导航目录
C0603C683K5RACAUTO数据手册
Page:
of 1 Go
若手册格式错乱，请下载阅览PDF原文件
Generated - fb984fa6-7e49-4618-b13d-8cd8d07e5de8
KEMET Part Number: C0603C683K5RACAUTO
Ceramic, AUTO-(CxxxxC-AUTO), 0.068 uF, 10%, 50 V, 0603, X7R, SMD, MLCC, Temperature Stable, Automotive Grade
Dimensions
L 1.6mm +/-0.15mm
W 0.8mm +/-0.15mm
T 0.8mm +/-0.07mm
S 0.7mm MIN
B 0.35mm +/-0.15mm
Packaging Specifications
Packaging: T&R, 180mm, Paper Tape
Packaging Quantity: 4000
General Information
Style: SMD Chip
Series: AUTO-(CxxxxC-AUTO)
Chip Size: 0603
Description:
SMD, MLCC, Temperature
Stable, Automotive Grade
Features:
Temperature Stable, Automotive
Grade
RoHS: Yes
Termination: Tin
Marking: No
Failure Rate: N/A
Approvals: AEC-Q200
AEC-Q200: Yes
Miscellaneous:
Note: Referee time for X7R
dielectric for this part number is
1000 hours
Specifications
Capacitance: 0.068 uF
Capacitance Tolerance: 10%
Voltage DC: 50 VDC
Temperature Range: -55/+125C
Temperature Coefficient: X7R
Dissipation Factor: 2.5%
Aging Rate: 3% Loss/Decade Hour
Insulation Resistance: 7.35 GOhms
Dielectric Strength: 125 V
© 2006 - 2017 IntelliData.net
Statements of suitability for certain applications are based on our knowledge of typical operating conditions for such applications, but are not intended to constitute - and
we specifically disclaim - any warranty concerning suitability for a specific customer application or use. This Information is intended for use only by customers who have the
requisite experience and capability to determine the correct products for their application. Any technical advice inferred from this Information or otherwise provided by us
with reference to the use of our products is given gratis, and we assume no obligation or liability for the advice given or results obtained.
