C0805C103K5RACAUTO 其他数据使用手册 - KEMET Corporation（基美）
制造商:
KEMET Corporation（基美）
分类:
陶瓷电容
封装:
0805
描述:
KEMET C0805C103K5RACAUTO 多层陶瓷电容器, 表面贴装, AEC-Q200 MLCC系列, 0.01 µF, ± 10%, X7R, 50 V, 0805 [2012 公制]
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
典型应用电路图在P1
型号编码规则在P1
封装信息在P1
应用领域在P1
导航目录
C0805C103K5RACAUTO数据手册
Page:
of 6 Go
若手册格式错乱，请下载阅览PDF原文件
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com CC103_AUTO • 10/21/2011
19
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com C1023_X7R_AUTO_SMD • 10/21/2011 1
One WORLD One Brand One Strategy One Focus One Team One KEMET
Bene ts
• AEC Q200 automotive qualifi ed
• -55°C to +125°C operating temperature range
• Pb-Free and RoHS compliant
• Temperature stable dielectric
• EIA 0402, 0603, 0805, 1206, 1210, 1812, and 2220 case sizes
• DC voltage ratings of 6.3V, 10V, 16V, 25V, 50V, 100V and 200V
• Capacitance offerings ranging from 150pF to 22μF
• Available capacitance tolerances of ±5%, ±10% and ±20%
• Non-polar device, minimizing installation concerns
• 100% pure matte tin-plated termination fi nish allowing for
excellent solderability
Applications
Typical applications include decoupling, bypass, fi ltering and
transient voltage suppression.
Overview
KEMET’s Automotive Grade Series surface mount capacitors in
X7R dielectric are suited for a variety of applications requiring
reliable operation. Whether under-hood or in-cabin, these devices
emphasize the vital and robust nature of capacitors required for
mission and safety critical automotive circuits. Stricter testing
protocal and inspection criteria have been established for
automotive grade products in recognition of potentially harsh
environmental conditions . KEMET automotive grade series
capacitors meet the demanding Automotive Electronics Council's
AEC-Q200 qualifi cation requirements and are manufactured in
state of the art ISO/TS 16949:2002 certifi ed facilities.
X7R dielectric features a 125°C maximum operating temperature
and is considered “temperature stable,” The Electronics
Components, Assemblies & Materials Association (EIA)
characterizes X7R dielectric as a Class II material. Components
of this classifi cation are fi xed, ceramic dielectric capacitors
suited for bypass and decoupling applications or for frequency
discriminating circuits where Q and stability of capacitance
characteristics are not critical. X7R exhibits a predictable change
in capacitance with respect to time and voltage and boasts
a minimal change in capacitance with reference to ambient
temperature. Capacitance change is limited to ±15% from -55°C
to +125°C.
Surface Mount Multilayer Ceramic Chip Capacitors (SMD MLCCs)
X7R Dielectric, 6.3VDC-200VDC (Automotive Grade)
1
Additional termination nish options may be available. Contact KEMET for details
2
Additional reeling or packaging options may be available. Contact KEMET for details.
Ordering Information
C 0805 C 225 M 4 R A C AUTO
Ceramic
Case Size
(L" x W")
Specifi cation/
Series
Capacitance
Code (pF)
Capacitance
Tolerance
Voltage Dielectric
Failure Rate/
Design
Termination Finish
1
Packaging/Grade
(C-Spec)
3
0402
0603
0805
1206
1210
1812
2220
C = Standard 2 Sig. Digits +
Number of Zeros
J = ±5%
K = ±10%
M = ±20%
9 = 6.3V
8 = 10V
4 = 16V
3 = 25V
5 = 50V
1 = 100V
2 = 200V
R = X7R A = N/A C = 100% Matte Sn AUTO = Automotive
Grade 7" Reel
Unmarked
