© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com C1008_X8L_150C_SMD • 1/14/2013 1
One world. One KEMET
Overview
KEMET’s X8L dielectric features a 150°C maximum operating
temperature and is considered “general purpose high
temperature.” These components are xed, ceramic dielectric
capacitors suited for high temperature bypass and decoupling
applications or frequency discriminating circuits where Q and
stability of capacitance characteristics are not critical. X8L
exhibits a predictable change in capacitance with respect to time
and voltage and boasts a minimal change in capacitance with
reference to ambient temperature up to 125°C. Beyond 125°C
X8L displays a wider variation in capacitance. Capacitance
change is limited to ±15% from -55°C to +125°C and +15, -40%
from 125°C to 150°C.
Driven by the demand for a more robust and reliable
component, X8L dielectric capacitors were developed for critical
applications where reliability at higher operating temperatures
are a concern. These capacitors are widely used in automotive
circuits as well as general high temperature applications.
Concerned with ex cracks resulting from excessive tensile and
shear stresses produced during board exure and thermal cycling?
These devices are available with KEMET's Flexible termination
technology which inhibits the transfer of board stress to the rigid
ceramic body, therefore mitigating ex cracks which can result
in low IR or short circuit failures. Although exible termination
technology does not eliminate the potential for mechanical damage
that may propagate during extreme environmental and handling
conditions, it does provide superior ex performance over standard
termination systems.
In addition to commercial grade, automotive grade devices
are available and meet the demanding Automotive Electronics
Council's AEC–Q200 qualication requirements.
Surface Mount Multilayer Ceramic Chip Capacitors (SMD MLCCs)
High Temperature 150°C, X8L Dielectric, 10 – 50 VDC
(Commercial & Automotive Grade)
Ordering Information
C 1210 X 106 K 8 N A C TU
Ceramic
Case Size
(L" x W")
Specication/
Series
1
Capacitance
Code (pF)
Capacitance
Tolerance
Voltage Dielectric
Failure Rate/
Design
Termination Finish
2
Packaging/Grade
(C-Spec)
3
0402
0603
0805
1206
1210
C = Standard
X = Flexible
Termination
2 Signicant
Digits + Number
of Zeros
J = ±5%
K = ±10%
M = ±20%
8 = 10 V
3 = 25 V
5 = 50 V
N = X8L A = N/A C = 100% Matte Sn
L = SnPb (5%
minimum)
Blank = Bulk
TU = 7" Reel
Unmarked
TM = 7" Reel Marked
AUTO = Automotive
Grade 7" Reel
Unmarked
1
The exible termination option is not available on EIA 0402 case size product. "C" must be used in the 6th character position when ordering this case size.
2
Additional termination nish options may be available. Contact KEMET for details.
2, 3
SnPb termination nish option is not available on Automotive Grade product.
3
Additional reeling or packaging options may be available. Contact KEMET for details.
