© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com C1003_C0G • 3/30/2016 1

One world. One KEMET

Benets

• −55°Cto+125°Coperatingtemperaturerange

• Lead (Pb)-Free, RoHS, and REACH compliant

• EIA 0201, 0402, 0603, 0805, 1206, 1210, 1808, 1812, 1825,

2220, and 2225 case sizes

• DCvoltageratingsof10V,16V,25V,50V,100V,200Vand250V

• Capacitanceofferingsrangingfrom0.5pFupto0.47μF

Overview

KEMET’sC0Gdielectricfeaturesa125°Cmaximumoperating

temperatureandisconsidered“stable.”TheElectronics

Components, Assemblies & Materials Association (EIA)

characterizesC0GdielectricasaClassImaterial.Components

ofthisclassicationaretemperaturecompensatingandare

suitedforresonantcircuitapplicationsorthosewhereQ

andstabilityofcapacitancecharacteristicsarerequired.C0G

exhibitsnochangeincapacitancewithrespecttotimeand

voltageandboastsanegligiblechangeincapacitancewith

Ceramic

Case Size

(L" x W")

Dielectric

1 = 100

2 = 200

A = 250

below
