Rev. 0.2 7/13 Copyright © 2013 by Silicon Laboratories C8051F800-DK
C8051F800-DK
C8051F800 DEVELOPMENT KIT USER’S GUIDE
1. Relevant Devices
The C8051F800 Development Kit is intended as a development platform for the microcontrollers in the
C8051F80x-83x MCU family. The members of this MCU family are as follows: C8051F800, C8051F801,
C8051F802, C8051F803, C8051F804, C8051F805, C8051F806, C8051F807, C8051F808, C8051F809,
C8051F810, C8051F811, C8051F812, C8051F813, C8051F814, C8051F815, C8051F816, C8051F817,
C8051F818, C8051F819, C8051F820, C8051F821, C8051F822, C8051F823, C8051F824, C8051F825,
C8051F826, C8051F827, C8051F828, C8051F829, C8051F830, C8051F831, C8051F832, C8051F833,
C8051F834, and C8051F835.
The target board included in this kit is provided with a pre-soldered C8051F800-GM MCU (QFN20 package).
Code developed on the C8051F800 can be easily ported to the other members of this MCU family.
Refer to the C8051F80x-83x data sheet for the differences between the members of this MCU family.
The C8051F80x-GM and C8051F81x-GM devices (QFN20 package) are pin-compatible with the C8051F330/1/
2/3/4/5/6/7 devices.
2. Kit Contents
The C8051F800 Development Kit contains the following items:
C8051F800 Target Board
C8051Fxxx Development Kit Quick-Start Guide
Silicon Labs IDE and Product Information CD-ROM. CD content includes the following:
Silicon Labs Integrated Development Environment (IDE)
Evaluation assembler, compiler, and linker tools
Source code examples and register definition files
Documentation
Optional Third Party Tools CD
AC to DC Power Adapter
USB Debug Adapter
Two USB Cables
3. Hardware Setup
Refer to Figure 1 for a diagram of the hardware configuration.
1. Connect the USB Debug Adapter to the DEBUG connector on the target board with the 10-pin ribbon cable.
2. Connect one end of the USB cable to the USB connector on the USB Debug Adapter.
3. Verify that shorting blocks are installed on the target board as shown in Figure 4 on page 8.
4. Connect the other end of the USB cable to a USB Port on the PC.
5. Connect the ac/dc power adapter to power jack P4 on the target board.
Notes:
Use the Reset icon in the IDE to reset the target when connected during a debug session.
Remove power from the target board and the USB Debug Adapter before connecting or disconnecting the
ribbon cable from the target board. Connecting or disconnecting the cable when the devices have power can
damage the device and/or the USB Debug Adapter.
