SEATING
PLANE
NOTES:
1. DIMENSIONING AND TOLERANCING PER ASME
Y14.5M, 1994.
2. CONTROLLING DIMENSION: MILLIMETERS.
3. DATUM C, THE SEATING PLANE, IS DEFINED BY
THE SPHERICAL CROWNS OF THE CONTACT
BALLS.
4. COPLANARITY APPLIES TO SPHERICAL CROWNS
OF THE CONTACT BALLS.
5. DIMENSION b IS MEASURED AT THE MAXIMUM
CONTACT BALL DIAMETER PARALLEL TO DATUM C.
È
D
E
A B
PIN A1
REFERENCE
e
0.05 C
4X b
12
B
A
0.05 C
A1
C
TOP VIEW
SIDE VIEW
BOTTOM VIEW
NOTE 4
e
NOTE 3
A
DETAIL A
DETAIL A
A2
A3
OPTIONAL
BACKSIDE COAT
WLCSP4, 0.84x0.86
CASE 567DC
ISSUE F
DATE 14 Jul 2016
SCALE 4:1
PITCH
0.18
4X
DIMENSIONS: MILLIMETERS
*For additional information on our Pb−Free strategy and soldering
details, please download the ON Semiconductor Soldering and
Mounting Techniques Reference Manual, SOLDERRM/D.
SOLDERING FOOTPRINT*
0.40
0.40
RECOMMENDED
A1
PACKAGE
OUTLINE
PITCH
GENERIC
MARKING DIAGRAM*
X = Specific Device Code
Y = Year
M = Date Code
*This information is generic. Please refer to
device data sheet for actual part marking.
Pb−Free indicator, “G” or microdot “ G”,
may or may not be present.
X
Y M
NOTE 5
A0.05 BC
0.03 C
DIM
A
MIN NOM
−−−
MILLIMETERS
A1
D
E
b 0.16 0.18
e 0.40 BSC
−−−
0.08 0.10
A2 0.23 REF
A3 0.025 REF
MAX
0.20
0.38
0.12
0.82 0.84 0.86
0.84 0.86 0.88
MECHANICAL CASE OUTLINE
PACKAGE DIMENSIONS
http://onsemi.com
1
© Semiconductor Components Industries, LLC, 2002
October, 2002 − Rev. 0
Case Outline Number:
XXX
DOCUMENT NUMBER:
STATUS:
NEW STANDARD:
DESCRIPTION:
98AON56821E
ON SEMICONDUCTOR STANDARD
WLCSP4, 0.84X0.86
Electronic versions are uncontrolled except when
accessed directly from the Document Repository. Printed
versions are uncontrolled except when stamped
“CONTROLLED COPY” in red.
PAGE 1 OF 2
