An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
CC110L
SWRS109C –MAY 2011–REVISED DECEMBER 2016
CC110L Value Line Transceiver
1 Device Overview
1
1.1 Features
1
• RF Performance
– Programmable Output Power up to +12 dBm
– Receive Sensitivity Down to −116 dBm at
0.6 kbps
– Programmable Data Rate from 0.6 to 600 kbps
– Frequency Bands: 300–348 MHz,
387–464 MHz, and 779–928 MHz
– 2-FSK, 4-FSK, GFSK, MSK, and OOK
Supported
• Digital Features
– Flexible Support for Packet Oriented Systems
– On-chip Support for Sync Word Insertion,
Flexible Packet Length, and Automatic CRC
Calculation
• Low-Power Features
– 200-nA Sleep Mode Current Consumption
– Fast Startup Time; 240 μs From Sleep to RX
Mode or TX Mode
– 64-Byte RX and TX FIFO
• Improved Range Using CC1190
– The CC1190 is a Range Extender for
850–950 MHz and is an Ideal Fit for CC110L to
Enhance RF Performance
– High Sensitivity
– –118 dBm at 1.2 kBaud, 868 MHz, 1%
Packet Error Rate
– –120 dBm at 1.2 kBaud, 915 MHz, 1%
Packet Error Rate
– +20-dBm Output Power at 868 MHz
– +26-dBm Output Power at 915 MHz
• General
– Few External Components; Completely On-chip
Frequency Synthesizer, No External Filters or
RF Switch Needed
– Green Package: RoHS Compliant and No
Antimony or Bromine
– Small Size (QLP 4- x 4-mm Package, 20 Pins)
– Suited for Systems Targeting Compliance with
EN 300 220 (Europe) and FCC CFR Part 15
(US)
– Support for Asynchronous and Synchronous
Serial Transmit Mode for Backward
Compatibility with Existing Radio
Communication Protocols
1.2 Applications
• Ultra Low-Power Wireless Applications Operating
in the 315-, 433-, 868-, 915-MHz ISM or SRD
Bands
• Wireless Alarm and Security Systems
• Industrial Monitoring and Control
• Remote Controls
• Toys
• Home and Building Automation
1.3 Description
The CC110L is a cost optimized sub-1 GHz RF transceiver for the 300–348 MHz, 387–464 MHz, and
779–928 MHz frequency bands. The circuit is based on the popular CC1101 RF transceiver, and RF
performance characteristics are identical. Two CC110L transceivers together enable a low-cost
bidirectional RF link.
The RF transceiver is integrated with a highly configurable baseband modem. The modem supports
various modulation formats and has a configurable data rate up to 600 kbps.
The CC110L provides extensive hardware support for packet handling, data buffering, and burst
transmissions.
The main operating parameters and the 64-byte receive and transmit FIFOs of CC110L can be controlled
through a serial peripheral interface (SPI). In a typical system, the CC110L will be used together with a
microcontroller and a few additional passive components.
