CC113L
SWRS108B –MAY 2011–REVISED JUNE 2014
CC113L Value Line Receiver
1 Device Overview
1.1 Features
1
• RF Performance • General
– Receive Sensitivity Down to −116 dBm at – Few External Components; Completely On-chip
0.6 kbps Frequency Synthesizer, No External Filters or
RF Switch Needed
– Programmable Data Rate from 0.6 to 600 kbps
– Green Package: RoHS Compliant and No
– Frequency Bands: 300–348 MHz,
Antimony or Bromine
387–464 MHz, and 779–928 MHz
– Small Size (QLP 4- x 4-mm Package, 20 Pins)
– 2-FSK, 4-FSK, GFSK, MSK, and OOK
Supported – Suited for Systems Targeting Compliance with
EN 300 220 (Europe) and FCC CFR Part 15
• Digital Features
(US)
– Flexible Support for Packet Oriented Systems
– Support for Asynchronous and Synchronous
– On-chip Support for Sync Word Detection,
Serial Transmit Mode for Backward
Flexible Packet Length, and Automatic CRC
Compatibility with Existing Radio
Calculation
Communication Protocols
• Low-Power Features
– 200-nA Sleep Mode Current Consumption
– Fast Startup Time; 240 μs From Sleep to RX
Mode
– 64-Byte RX FIFO
1.2 Applications
• Ultra Low-Power Wireless Applications Operating • Industrial Monitoring and Control
in the 315-, 433-, 868-, 915-MHz ISM or SRD
• Remote Controls
Bands
• Toys
• Wireless Alarm and Security Systems
• Home and Building Automation
1.3 Description
The CC113L is a cost optimized sub-1 GHz RF receiver for the 300–348 MHz, 387–464 MHz, and
779–928 MHz frequency bands. The circuit is based on the popular CC1101 RF transceiver, and RF
performance characteristics are identical. The CC115L transmitter together with the CC113L receiver
enable a low-cost RF link.
The RF receiver is integrated with a highly configurable baseband demodulator. The modem supports
various modulation formats and has a configurable data rate up to 600 kbps.
The CC113L provides extensive hardware support for packet handling, data buffering, and burst
transmissions.
The main operating parameters and the 64-byte receive FIFO of CC113L can be controlled through a
serial peripheral interface (SPI). In a typical system, the CC113L will be used together with a
microcontroller and a few additional passive components.
Device Information
(1)
PART NUMBER PACKAGE BODY SIZE
CC113LRGP QFN (20) 4.00 mm × 4.00 mm
(1) For more information on these devices, see Section 8, Mechanical Packaging and Orderable
Information.
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
