An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
CC1310
SWRS181C –SEPTEMBER 2015–REVISED OCTOBER 2016
CC1310 SimpleLink™ Ultra-Low-Power Sub-1 GHz Wireless MCU
1 Device Overview
1
1.1 Features
1
• Microcontroller
– Powerful ARM
®
Cortex
®
-M3 Processor
– EEMBC CoreMark
®
Score: 142
– EEMBC ULPBench™ Score: 158
– Clock Speed up to 48-MHz
– 32KB, 64KB, and 128KB of In-System
Programmable Flash
– 8KB of SRAM for Cache
(or as General-Purpose RAM)
– 20KB of Ultra-Low-Leakage SRAM
– 2-Pin cJTAG and JTAG Debugging
– Supports Over-the-Air (OTA) Update
• Ultra-Low-Power Sensor Controller
– Can Run Autonomously From the Rest of the
System
– 16-Bit Architecture
– 2KB of Ultra-Low-Leakage SRAM for Code and
Data
• Efficient Code-Size Architecture, Placing Parts of
TI-RTOS, Drivers, and Bootloader in ROM
• RoHS-Compliant Package
– 7-mm × 7-mm RGZ VQFN48 (30 GPIOs)
– 5-mm × 5-mm RHB VQFN32 (15 GPIOs)
– 4-mm × 4-mm RSM VQFN32 (10 GPIOs)
• Peripherals
– All Digital Peripheral Pins Can Be Routed to
Any GPIO
– Four General-Purpose Timer Modules
(Eight 16-Bit or Four 32-Bit Timers, PWM Each)
– 12-Bit ADC, 200 ksamples/s, 8-Channel Analog
MUX
– Continuous Time Comparator
– Ultra-Low-Power Clocked Comparator
– Programmable Current Source
– UART
– 2× SSI (SPI, MICROWIRE, TI)
– I
2
C, I2S
– Real-Time Clock (RTC)
– AES-128 Security Module
– True Random Number Generator (TRNG)
– Support for Eight Capacitive Sensing Buttons
– Integrated Temperature Sensor
SPACER
SPACER
SPACER
SPACER
• External System
– On-Chip Internal DC-DC Converter
– Seamless Integration With the SimpleLink™
CC1190 Range Extenders
• Low Power
– Wide Supply Voltage Range: 1.8 to 3.8 V
– RX: 5.4 mA
– TX at +10 dBm: 13.4 mA
– Active-Mode MCU 48 MHz Running Coremark:
2.5 mA (51 µA/MHz)
– Active-Mode MCU: 48.5 CoreMark/mA
– Active-Mode Sensor Controller at 24 MHz:
0.4 mA + 8.2 µA/MHz
– Sensor Controller, One Wakeup Every Second
Performing One 12-Bit ADC Sampling: 0.95 µA
– Standby: 0.7 µA (RTC Running and RAM and
CPU Retention)
– Shutdown: 185 nA (Wakeup on Extexternernal
Events)
• RF Section
– Excellent Receiver Sensitivity –124 dBm Using
Long-Range Mode, –110 dBm at 50 kbps
(Sub-1 GHz)
– Excellent Selectivity (±100 kHz): 56 dB
– Excellent Blocking Performance (±10 MHz):
90 dB
– Programmable Output Power up to +15 dBm
– Single-Ended or Differential RF Interface
– Suitable for Systems Targeting Compliance With
Worldwide Radio Frequency Regulations
• ETSI EN 300 220, EN 303 204 (Europe)
• FCC CFR47 Part 15 (US)
• ARIB STD-T108 (Japan)
– Wireless M-Bus and Selected IEEE
®
802.15.4g
PHY
• Tools and Development Environment
– Full-Feature and Low-Cost Development Kits
– Multiple Reference Designs for Different RF
Configurations
– Packet Sniffer PC Software
– Sensor Controller Studio
– SmartRF™ Studio
– SmartRF Flash Programmer 2
– IAR Embedded Workbench
®
for ARM
– Code Composer Studio™
