CC1350
SWRS183A –JUNE 2016–REVISED NOVEMBER 2016
CC1350 SimpleLink™ Ultra-Low-Power Dual-Band Wireless MCU
1 Device Overview
1
1.1 Features
1
• World's First Dual-Band (Sub-1 GHz and 2.4 GHz)
Wireless Microcontroller
• Microcontroller
– Powerful ARM
®
Cortex
®
-M3 Processor
– EEMBC CoreMark
®
Score: 142
– EEMBC ULPBench™ Score: 158
– Clock Speed up to 48-MHz
– 128KB of In-System Programmable Flash
– 8KB of SRAM for Cache
(or as General-Purpose RAM)
– 20KB of Ultra-Low-Leakage SRAM
– 2-Pin cJTAG and JTAG Debugging
– Supports Over-the-Air (OTA) Update
• Ultra-Low-Power Sensor Controller
– Can Run Autonomously From the Rest of the
System
– 16-Bit Architecture
– 2KB of Ultra-Low-Leakage SRAM for Code and
Data
• Efficient Code-Size Architecture, Placing Parts of
TI-RTOS, Drivers, Bluetooth
®
low energy
Controller and Bootloader in ROM
• RoHS-Compliant Package
– 7-mm × 7-mm RGZ VQFN48 (30 GPIOs)
– 5-mm × 5-mm RHB VQFN32 (15 GPIOs)
– 4-mm × 4-mm RSM VQFN32 (10 GPIOs)
• Peripherals
– All Digital Peripheral Pins Can Be Routed to
Any GPIO
– Four General-Purpose Timer Modules
(Eight 16-Bit or Four 32-Bit Timers, PWM Each)
– 12-Bit ADC, 200 ksamples/s, 8-Channel Analog
MUX
– Continuous Time Comparator
– Ultra-Low-Power Clocked Comparator
– Programmable Current Source
– UART
– 2× SSI (SPI, MICROWIRE, TI)
– I
2
C, I2S
– Real-Time Clock (RTC)
– AES-128 Security Module
– True Random Number Generator (TRNG)
– Support for Eight Capacitive Sensing Buttons
– Integrated Temperature Sensor
SPACER
SPACER
SPACER
SPACER
• External System
– On-Chip Internal DC-DC Converter
– Seamless Integration With the SimpleLink™
CC1190 and CC2592 Range Extenders
• Low Power
– Wide Supply Voltage Range: 1.8 to 3.8 V
– RX: 5.4 mA (Sub-1 GHz), 6.4 mA (Bluetooth low
energy, 2.4 GHz)
– TX at +10 dBm: 13.4 mA (Sub-1 GHz)
– TX at +9 dBm: 22.3 mA (Bluetooth low energy,
2.4 GHz)
– TX at +0 dBm: 10.5 mA (Bluetooth low energy,
2.4 GHz)
– Active-Mode MCU 48 MHz Running Coremark:
2.5 mA (51 µA/MHz)
– Active-Mode MCU: 48.5 CoreMark/mA
– Active-Mode Sensor Controller at 24 MHz:
0.4 mA + 8.2 µA/MHz
– Sensor Controller, One Wakeup Every Second
Performing One 12-Bit ADC Sampling: 0.95 µA
– Standby: 0.7 µA (RTC Running and RAM and
CPU Retention)
– Shutdown: 185 nA (Wakeup on External Events)
• RF Section
– 2.4-GHz RF Transceiver Compatible With
Bluetooth low energy 4.2 Specification
– Excellent Receiver Sensitivity –124 dBm Using
Long-Range Mode, –110 dBm at 50 kbps
(Sub-1 GHz),
–87 dBm at Bluetooth low energy
– Excellent Selectivity (±100 kHz): 56 dB
– Excellent Blocking Performance (±10 MHz):
90 dB
– Programmable Output Power up to +15 dBm
(Sub-1 GHz) and +9 dBm at 2.4 GHz (Bluetooth
low energy)
– Single-Ended or Differential RF Interface
– Suitable for Systems Targeting Compliance With
Worldwide Radio Frequency Regulations
– ETSI EN 300 220, EN 303 204 (Europe)
– EN 300 440 Class 2 (Europe)
– EN 300 328 (Europe)
– FCC CFR47 Part 15 (US)
– ARIB STD-T66 (Japan)
– ARIB STD-T108 (Japan)
