CC2541-Q1
SWRS128 –JUNE 2014
CC2541-Q1 SimpleLink™ Bluetooth
®
Low Energy Wireless MCU for Automotive
1 Device Overview
1.1 Features
1
– Accurate Digital RSSI Support
• RF
– Battery Monitor and Temperature Sensor
– 2.4-GHz Bluetooth Low Energy Compliant and
Proprietary RF Wireless MCU – 12-Bit ADC With Eight Channels and
Configurable Resolution
– Supports Data Rates of 250 kbps, 500 kbps, 1
Mbps, and 2 Mbps – AES Security Coprocessor
– Excellent Link Budget, Enabling Long-Range – Two Powerful USARTs With Support for Several
Applications Without External Front End Serial Protocols
– Programmable Output Power up to 0 dBm – 23 General-Purpose I/O Pins
(21 × 4 mA, 2 × 20 mA)
– Excellent Receiver Sensitivity (–94 dBm at
1 Mbps), Selectivity, and Blocking Performance – I
2
C interface
– Suitable for Systems Targeting Compliance With – 2 I/O Pins Have LED Driving Capabilities
Worldwide Radio Frequency Regulations: ETSI
– Watchdog Timer
EN 300 328 and EN 300 440 Class 2 (Europe),
– Integrated High-Performance Comparator
FCC CFR47 Part 15 (US), and ARIB STD-T66
• Development Tools
(Japan)
– CC2541 Evaluation Module
• Layout
– SmartRF™ Software
– Few External Components
– IAR Embedded Workbench™ Available
– 6 mm × 6 mm QFN-40 Package
• Bluetooth v4.0 Compliant Protocol Stack for
• Low Power
Single-Mode BLE Solution
– Active-Mode RX Down to: 18.3 mA
– Complete Power-Optimized Stack, Including
– Active-Mode TX (0 dBm): 18.6 mA
Controller and Host
– Power Mode 1 (4-µs Wake-Up): 270 µA
• GAP – Central, Peripheral, Observer, or
– Power Mode 2 (Sleep Timer On): 1 µA
Broadcaster (Including Combination Roles)
– Power Mode 3 (External Interrupts): 0.5 µA
• ATT / GATT – Client and Server
– Wide Supply-Voltage Range (2 V to 3.6 V)
• SMP – AES-128 Encryption and Decryption
• Microcontroller
• L2CAP
– High-Performance and Low-Power 8051
– Sample Applications and Profiles
Microcontroller Core With Code Prefetch
• Generic Applications for GAP Central and
– 256KB In-System Programmable Flash
Peripheral Roles
– 8KB of RAM With Retention in All Power Modes
• Proximity, Accelerometer, Simple Keys, and
– Hardware Debug Support
Battery GATT Services
– Extensive Baseband Automation, Including
• More Applications Supported in BLE
Auto-Acknowledgment and Address Decoding
Software Stack
– Retention of All Relevant Registers in All Power
– Multiple Configuration Options
Modes
• Single-Chip Configuration, Allowing
• Peripherals
Applications to Run on CC2541-Q1
– Powerful Five-Channel DMA
• Network Processor Interface for Applications
Running on an External Microcontroller
– IR Generation Circuitry
– BTool–Windows PC Application for Evaluation,
– General-Purpose Timers (One 16-Bit, Two 8-Bit)
Development, and Test
– 32-kHz Sleep Timer With Capture
– Over the Air Update Capable
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
