(2.54 mm) .100"
SLW, CES SERIES
SLW–110–01–T–D
CES–115–01–T–S
CES–125–02–L–D
SLW–120–01–G–S
WWW.SAMTEC.COM
Due to technical progress, all designs, specifications and components are subject to change without notice.
(0.25)
.010
A
–01
= (3.25 mm)
.128
“A” Dim.
NO. PINS
PER ROW
1
SLW
ROW
OPTION
PLATING
OPTION
01
NO. PINS
PER ROW
LEAD
STYLE
CES
1
– S
= Single
Row
– D
= Double
Row
PLATING
OPTION
RA
OPTION
Mates with:
TLW, TSW, MTLW, MTSW,
HW, EW, ZW, HTSW, HMTSW, TSM
Mates with:
TLW, TSW, MTLW,
MTSW, HW, EW, ZW, DW,
HTSW, PHT, HMTSW
ROW
OPTION
– D
= Double
Row
– S
= Single
Row
(3.05)
.120
(1.02)
.040
– RA
= Right-angle
version
Style – 02 only
Single Row only
(2.54)
.100
(0.51)
.020
(5.08)
.200
(0.64)
.025
(2.54) .100 X No. of Positions
(2.54)
.100
01
01
02
02
(0.71)
.028 SQ
(3.05)
.120
TYP
(5.59)
.220
(2.54)
.100
Note: Some lengths,
styles and options are
non-standard, non-returnable.
–L
= 10 µ" (0.25 µm)
Gold contact,
Matte Tin on tail
–T
= Matte Tin
(2.54) .100 X No. of Positions
(4.95)
.195
(2.54)
.100
(2.54)
.100
01
01
02
02
(2.54) .100
(4.57)
.180
(0.64) .025
(0.41) .016
(2.54) .100
(2.92)
.115
TYP
–F
= Gold flash on contact,
Matte Tin on tail
–L
= 10 µ" (0.25 µm) Gold on contact,
Matte Tin on tail
–G
= 20 µ" (0.51 µm) Gold on contact,
Gold flash on balance
–T
= Matte Tin
01 thru 50
F-215 (Rev 02SEP16)
–02
= (5.66 mm)
.223
“A” Dim.
For complete specifications
see www.samtec.com?SLW
or www.samtec.com?CES
Insulator Material:
Black G.F. Polyester
Contact Material:
Phosphor Bronze
Plating: Au or Sn over
50 µ"(1.27 µm) Ni
SLW Current Rating
(SLW/TSW):
5.2 A per pin
(1 pin powered per row)
CES Current Rating
(TSW/CES):
5.5 A per pin
(1 pin powered per row)
Voltage Rating:
SLW: 406 VAC
CES: 400 VAC
Operating Temp Range:
-55 °C to +125 °C with Gold
-55 °C to +105 °C with Tin
Contact Resistance:
10 mW
Insertion Depth:
SLW: (2.16 mm) .085" to
(2.92 mm) .115"
CES: (2.62 mm) .103" to
(4.06 mm) .160"
RoHS Compliant:
Ye s
Lead-Free Solderable:
No, Lead Wave only
SPECIFICATIONS
Dual leaf
folded
contact
Chamfered
Closed bottom
contact
LOW PROFILE SOCKET STRIPS
For complete scope
of recognitions see
www.samtec.com/quality
RECOGNITIONS
(CES ONLY)
ALSO AVAILABLE
(MOQ Required)
• Other platings
Contact Samtec.
01 thru 50
FILE NO. E111594
FILE NO: 090871_0_000
