SPECIFICATION
•
••
•
Supplier : Samsung electro-mechanics •
••
•
Samsung P/N :
CL10C101JB8NCNC
•
••
•
Product : Multi-layer Ceramic Capacitor •
••
•
Description :
CAP, 100㎊
㎊㎊
㎊, 50V, ±5%, C0G, 0603
CL 10 C 101 J B 8 N C N C
①
①①
① ②
②②
② ③
③③
③ ④
④④
④ ⑤
⑤⑤
⑤ ⑥
⑥⑥
⑥ ⑦
⑦⑦
⑦ ⑧
⑧⑧
⑧ ⑨
⑨⑨
⑨ ⑩
⑩⑩
⑩ ⑪
⑪⑪
⑪
①
①①
① Series
Samsung Multi-layer Ceramic Capacitor
②
②②
② Size
0603 (inch code) L: 1.6 ± 0.1 mm W: ± 0.1 mm
③
③③
③ Dielectric
C0G
⑧
⑧⑧
⑧ Inner electrode
④
④④
④ Capacitance
100
㎊
Termination
⑤
⑤⑤
⑤ Capacitance
±5
%
Plating
(Pb Free)
tolerance ⑨
⑨⑨
⑨ Product
High-Q
⑥
⑥⑥
⑥ Rated Voltage
50 V
⑩
⑩⑩
⑩ Special
Reserved for future use
⑦
⑦⑦
⑦ Thickness
0.8 ± 0.1 mm
⑪
⑪⑪
⑪ Packaging
Cardboard Type, 7" reel
B. Samsung Reliablility Test and Judgement condition
Capacitance
Within specified tolerance
1㎒±10%
0.5~5Vrms
Q
1000 min
Insulation
10,000Mohm or 500Mohm⋅㎌
Rated Voltage 60~120 sec.
Resistance
Whichever is Smaller
Appearance
No abnormal exterior appearance
Microscope (×10)
Withstanding
No dielectric breakdown or of the rated voltage
Voltage
mechanical breakdown
Temperature
C0G
Characterisitcs
(From -55℃ to 125℃, Capacitance change shoud be within ±30PPM/℃)
Adhesive Strength
No peeling shall be occur on the
500g⋅F, for 10±1 sec.
of Termination
terminal electrode
Bending Strength
Capacitance change : Bending to the limit (1mm)
within ±5% or ±0.5㎊ whichever is larger
with 1.0mm/sec.
Solderability
More than 75% of terminal surface SnAg3.0Cu0.5 solder
is to be soldered newly
245±5℃, 3±0.3sec.
(preheating : 80~120℃ for 10~30sec.)
Resistance to
Capacitance change :
Solder pot : 270±5℃, 10±1sec.
Soldering heat
within ±2.5% or ±0.25㎊ whichever is larger
Tan δ, IR : initial spec.
Performance Test condition
300%
A. Samsung Part Number
Sn 100%
Cu
Ni
0.8
