SPECIFICATION
• Supplier : Samsung electro-mechanics • Samsung P/N :
CL10C151JB8NNND
•
Product : Multi-layer Ceramic Capacitor • Description :
CAP, 150㎊, 50V, ±5%, C0G, 0603
CL
10 C 151 J B 8 N N N D
① ②③ ④ ⑤⑥⑦⑧⑨⑩⑪
① Series
Samsung Multi-layer Ceramic Capacitor
② Size
0603 (inch code) L: 1.6 ± 0.1 mm W: ± 0.1 mm
③ Dielectric
C0G
⑧ Inner electrode
④ Capacitance
150
㎊
Termination
⑤ Capacitance
±5
%
Plating
(Pb Free)
tolerance ⑨ Product
Normal
⑥ Rated Voltage
50 V
⑩ Special
Reserved for future use
⑦ Thickness
0.8 ± 0.1 mm
⑪ Packaging
Cardboard Type, 13" reel
B. Samsung Reliablility Test and Judgement condition
Capacitance
Within specified tolerance
1㎒±10%
0.5~5Vrms
Q
1000 min
Insulation
10,000Mohm or 500Mohm⋅㎌
Rated Voltage 60~120 sec.
Resistance
Whichever is Smaller
Appearance
No abnormal exterior appearance
Microscope (×10)
Withstanding
No dielectric breakdown or of the rated voltage
Voltage
mechanical breakdown
Temperature
C0G
Characterisitcs
(From -55℃ to 125℃, Capacitance change shoud be within ±30PPM/℃)
Adhesive Strength
No peeling shall be occur on the
500g⋅F, for 10±1 sec.
of Termination
terminal electrode
Bending Strength
Capacitance change : Bending to the limit (1mm)
within ±5% or ±0.5㎊ whichever is larger
with 1.0mm/sec.
Solderability
More than 75% of terminal surface SnAg3.0Cu0.5 solder
is to be soldered newly
245±5℃, 3±0.3sec.
(preheating : 80~120℃ for 10~30sec.)
Resistance to
Capacitance change :
Solder pot : 270±5℃, 10±1sec.
Soldering heat
within ±2.5% or ±0.25㎊ whichever is larger
Tan δ, IR : initial spec.
Performance Test condition
300%
A. Samsung Part Number
Sn 100%
Cu
Ni
0.8
