CLA50E1200TC

Single Thyristor

High Efficiency Thyristor

2 1

Part number

CLA50E1200TC

Backside: anode

TAV

V V1,27

RRM

1200

Features / Advantages: Applications: Package:

● Thyristor for line frequency

● Planar passivated chip

● Long-term stability

● Line rectifying 50/60 Hz

● Softstart AC motor control

● DC Motor control

● Power converter

● AC power control

● Lighting and temperature control

TO-268AA (D3Pak)

● Industry standard outline

● RoHS compliant

● Epoxy meets UL 94V-0

The data contained in this product data sheet is exclusively intended for technically trained staff. The user will have to evaluate the suitability of the product for the intended application and

the completeness of the product data with respect to his application. The specifications of our components may not be considered as an assurance of component characteristics. The

information in the valid application- and assembly notes must be considered. Should you require product information in excess of the data given in this product data sheet or which concerns

the specific application of your product, please contact the sales office, which is responsible for you.

Due to technical requirements our product may contain dangerous substances. For information on the types in question please contact the sales office, which is responsible for you.

Should you intend to use the product in aviation, in health or live endangering or life support applications, please notify. For any such application we urgently recommend

- to perform joint risk and quality assessments;

- the conclusion of quality agreements;

- to establish joint measures of an ongoing product survey, and that we may make delivery dependent on the realization of any such measures.

Terms Conditions of usage:

IXYS reserves the right to change limits, conditions and dimensions.

20150827cData according to IEC 60747and per semiconductor unless otherwise specified
