CRG0603F330R 其他数据使用手册 - TE Connectivity（泰科）
制造商:
TE Connectivity（泰科）
分类:
贴片电阻
封装:
0603
描述:
0603 型 CRG0603 系列 SMD厚膜电阻器 CRG 系列具有高功率尺寸比，特别适用于工业和一般用途 1Ω 至 10M 范围，1% 和 5% 容差。 还包括 0Ω 链路。 由于短引线结构和低电容，适用于大多数应用，包括高频操作 七种封装尺寸 接线端子表面：无光泽锡 湿度敏感性等级：2 级 70°C 时功率 | 0.1W ---|--- 电阻容差 | ±1% 温度系数 | ±100ppm/°C 工作温度 | -55°C → +125°C 极限元件电压 | 150V 跳线芯片电阻 | 50mΩ（最大值） 70°C 时电流 | 1A（仅零欧姆电阻器） 尺寸（长x宽x厚） | 1.6 x 0.8 x 0.45 mm ### 厚膜 - 0402/0603
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
标记信息在P1
导航目录
CRG0603F330R数据手册
Page:
of 2 Go
若手册格式错乱，请下载阅览PDF原文件
Form Type Distribute Version 2.0 Ref IPC 1752A Sectionals Material Info Subsectionals D, A
Supplier Information
Company Name TE Connectivity Request
Document ID
Contact Name John R. Penica Contact Title Mgr. Global Product Compliance
Company
Unique ID
TE Connectivity Response Date 2015-04-03 Contact Email jrpenica@te.com
Contact Phone Number 717-592-3266
Legal Statement
Supplier
Acceptance
true
Legal Statement
The information provided in this document is based upon reasonable inquiry of our suppliers. This information is subject to change. This information does not in any
way modify existing purchase specifications or existing contractual or other agreements terms between TE Connectivity (or its affiliated companies) and its customers.
Product
Manufacturer
Item number
1622918-1 Amount 2.0773 Version - Identity
Manufacturer
Item Name
CRG0603 1%
330R
Weight Uom mg Mfr Site Authority
Date UOM Each
EURoHS-0508 Product(s) meets EU RoHS requirements by application of the selected exemption(s)
ChinaRoHS-
0508
Product(s) is NOT eligible for marking with the e code under China's Measures for Administration of the control of pollution by Electronic Information
Products
EUREACH-1213 REACH Candidate Substances of Very High Concern ARE NOT Contained in the Product Above the Limits per the Definition within REACH
Product Disclosure
Sub-
Item/Material/
Substance
Level Name Substance
Category
Substance
CAS
Substance
Concentration
Quantity Mass per Unit UOM Exemption
Material 1 Protective
coating G1
1.0 0.019 mg
Substance 2 Bismuth oxide
(Bi2O3)
Supplier 1304-76-3 53.12 1.0 0.0100928 mg
Substance 2 Copper oxide
(CuO)
Supplier 1317-38-0 0.78 1.0 1.482E-4 mg
Substance 2 Aluminum
oxide (Al2O3)
Supplier 1344-28-1 13.28 1.0 0.0025232 mg
Substance 2 Silicon oxide Supplier 11126-22-0 28.13 1.0 0.0053447 mg
Substance 2 Chromium
oxide (Cr2O3)
Supplier 1308-38-9 4.69 1.0 8.911E-4 mg
Material 1 Termination
inner C2
1.0 0.0222 mg
Substance 2 Silver Supplier 7440-22-4 95.0 1.0 0.02109 mg
Substance 2 Frits,
chemicals
Supplier 65997-18-4 5.0 1.0 0.00111 mg
Material 1 Resistive
element
1.0 0.01 mg
Substance 2 Frits,
chemicals
Supplier 65997-18-4 57.29 1.0 0.005729 mg
Substance 2 Silver Supplier 7440-22-4 35.0 1.0 0.0035 mg
Substance 2 Ruthenium
oxide (RuO2)
Supplier 12036-10-1 5.0 1.0 5.0E-4 mg
Substance 2 Lead Lead/Lead
Compounds
7439-92-1 2.71 1.0 2.71E-4 mg 7(c)-I Electrical
and electronic
components
containing lead
in a glass or
ceramic other
than dielectric
ceramic in
capacitors, e.g.
piezoelectronic
devices, or in a
glass or
ceramic matrix
compound
Material 1 Marking 1.0 0.0021 mg
Substance 2 Oxirane, 2,2-
[(1-
methylethylide
ne)bis(4,1-
phenyleneoxy
methylene)]bis-
, homopolymer
Supplier 25085-99-8 52.63 1.0 0.00110523 mg
Substance 2 Titanium oxide
(TiO2)
Supplier 13463-67-7 31.58 1.0 6.6318E-4 mg
Substance 2 Sulfuric acid,
barium salt
(1:1)
Supplier 7727-43-7 15.79 1.0 3.3159E-4 mg
