Ultimate System-Level Solution
AMD Geode™ CS5536 Companion Device
Design versatility: the features and
capabilities to create with freedom
The AMD Geode™ CS5536 companion device incorporates a full
suite of advanced features to enable designers to achieve new levels
of performance and creativity with x86-based devices. The
companion device contains:
• Versatile I/O functions
• 82xx devices to provide true PC functionality
– 2 PICs (Programmable Interrupt Controllers)
– PIT (Programmable Interval Timer) with 3 channels
– DMA (Direct Memory Access) functions
• Flexible MFGPTs (Multi-Function General Purpose Timers)
General features
• Designed for use with the AMD Geode LX and
GX processor families
• 208-Terminal PBGA (Plastic Ball Grid Array) package with
internal heatspreader
• 1.2V or 1.25V (nominal) core operation
• Working and Standby power domains
• IEEE 1149.1-compliant TAP and boundary scan
Technical specifications
• GeodeLink™ PCI Bridge (South Bridge)
– PCI v2.2 compliant
– 32-bit 33/66MHz operation
• GeodeLink™ Control Processor
– SUSP#/SUSPA# handshake with power management logic
provides Sleep control of all GeodeLink devices
Complementary tool for optimized
high-performance, low-power processing
Product overview
The AMD Geode™ CS5536 companion device works with both
the AMD Geode™ LX and AMD Geode™ GX processor families
to create today’s leading high-performance, low-power x86
solution for embedded applications, ranging from thin clients and
digital set-top boxes to single-board computers and Personal
Access Devices (PADs).
Architecture maximized
for performance
The AMD Geode CS5536 companion device leverages a single,
high-performance modular structure based on AMD GeodeLink™
architecture. This configuration provides internal data speeds
above 1 GB/second, and highly versatile internal power
management.
The AMD Geode CS5536 companion device is optimized to
work with the AMD Geode LX and GX processors to deliver an
integrated solution with the highest power/performance ratio
available in the industry today. The companion device contains
state-of-the-industry power management technology that enables
end products – especially battery-powered systems – to operate
with reduced power consumption.
A complete design solution
Together with the AMD Geode LX and GX processors,
the AMD Geode CS5536 companion device gives designers a
complete processing solution for developing a variety of end-user
devices that require high-performance x86-based processing and
low power usage. The companion device complements the
features built into the AMD Geode LX and GX processors, and
includes integrated controllers for audio, hard disk drive (ATA-6),
USB 2.0, power management, and more – all based on the
innovative GeodeLink architecture.
The AMD Geode CS5536 companion device supports the latest
high-speed USB 2.0 standard.
