CX380D5R 产品手册 - Crydom（快达）
制造商:
Crydom（快达）
分类:
固态继电器
封装:
SIP-4
描述:
CX 系列 SIL 固态继电器 ，12 至 660V 交流时为 5A罕有的浪涌等级和 5A 交流稳态等级 型号的开关范围在 48-660V 有效值 250A 峰值单循环浪涌性能 输入 - 输出电容：10pF 除非另有说明，零交叉开关为随机型 工作温度范围：- 30 至 +80°C 尺寸：33mm 高 x 7.6mm 宽 x 43.1mm 厚 ### 认可UL，CSA，VDE### Crydom 印刷电路板安装
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
封装尺寸在P3
型号编码规则在P3
技术参数、封装参数在P84
应用领域在P6
导航目录
CX380D5R数据手册
Page:
of 84 Go
若手册格式错乱，请下载阅览PDF原文件
All dimensions in drawings are in inches
[millimeters] and are for reference only.
Dimensional drawings shown are for illustrative
purposes only. They do not represent the complete
variety of products within each series. For complete
dimensional drawings for a particular Crydom
product visit the CAD Drawings section in the
Crydom website.
Part Number Nomenclature is color coded as
follows:
Required for valid part number
For options only and not required for valid part
number
Not all part number combinations are available.
Contact Crydom Sales Support for information on
the availability of a specific part number.
Safety agency approvals for SSR/Heat Sink
Assemblies may vary depending upon selected SSR.
Heat sinks do not require safety agency approval.
The standard Crydom SSR/Heat Sink Assemblies
are either DIN Rail or Panel Mounted depending
upon model selected and are available with either
one, two or three single or dual SSRs, or one three
phase SSR.
Installing a CN Series SSR in a socket that does not
have matching input/output specifications may
result in non operation or damage to either the SSR,
socket or both. See socket relay compatibility table
available in CN Series SSR datasheet.
In addition to the possible combinations shown in the
part number nomenclature, any standard Crydom
PCB Mount SIP type SSR with similar pin centers can
be offered as an assembly.
Listed agency approvals may not apply to all part
numbers available within a series. To determine
agency approvals for a specific part number contact
Crydom Technical Support.
Required external heat sink for all ratings.
Heat sink includes the necessary hardware to mount
the relay(s) onto the heat sink. The number of
hardware kits (HK1 or HKM1) included depends upon
the number and type of SSRs possible to install on
each heat sink.
ACDCACDCACDCACDC
Panel Mount
PCB Mount
DIN Rail Mount
Plug-In Mount
Assemblies
Accessories
Products included in this catalog are only part of the Crydom offer of Solid State Relays and Contactors. To facilitate
the use of this catalog, products have been categorized into 6 product groups mainly defined by mounting type.
The following conditions are applicable to product families where specifically noted:
A
C
B
D
E
F
G
H
K
L
J
About this catalog...
Page 8
Page 35
Page 47
Page 66
Page 71
Page 73
