RCWPM (Military M/D55342)
www.vishay.com
Vishay Dale
Revision: 23-Feb-11
2
Document Number: 31010
For technical questions, contact: ff2aresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
Notes
• For additional information on packaging, refer to the Surface Mount Resistor Packaging document (www.vishay.com/doc?31543
).
(1)
Products with space level failure rates are only offered in packaging codes with ESD overpack and labeling. For all other failure rates, the
ESD pack codes are an optional type of packaging.
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: M55342M02B10E0RWB (preferred part number format)
MIL
STYLE
CHARACTERISTICS
SPEC.
SHEET
TERMINATION
STYLE
VALUE AND
TOLERANCE
FAILURE
RATE
PACKAGING
(1)
SPECIAL
D55342
applies to
Style 07
(RM1206)
only.
M55342
applies to
all other
styles.
K = 100 ppm
M = 300 ppm
(see Standard
Electrical
Specifications
table)
B = Pre-tinned
nickel barrier,
wraparound
(see Tolerance
and Multipliers
table)
C = Non-ER
M = 1.0 %/1000 h
P = 0.1 %/1000 h
R = 0.01 %/1000 h
S = 0.001 %/1000 h
T = Space level
TP =
Tin/lead,
T/R (full)
TN
= Tin/lead,
T/R (full), w/ESD
UL
= Tin/lead, T/R
single lot date code
S3
= Tin/lead,
T/R (1000 pieces)
SV
= Tin/lead, T/R
(1000 pieces), w/ESD
WB
= Tin/lead,
waffle tray
WA
= Tin/lead,
waffle tray,
w/ESD
WL
= Tin/lead,
waffle tray,
single lot date code
S2
= Tin/lead,
T/R (500 pieces)
SU
= Tin/lead, T/R
(500 pieces), w/ESD
S6
= Tin/lead,
T/R (300 pieces)
ST
= Tin/lead, T/R
(300 pieces), w/ESD
Blank =
Standard
(Dash number)
(Up to 1 digits)
S =
Space level
w/option 1 part
marking (-97)
T =
Space level (-98)
2 =
Option 1
part marking
(-20)
3 =
Options 2 and 3
part marking
(-30)
Historical Part Numbering: M55342M02B10E0R (will continue to be accepted)
M55342 M 02 B 10E0 R WB
MIL
STYLE
CHARACTERISTICS SPEC. SHEET
TERMINATION
STYLE
VALUE AND
TOLERANCE
FAILURE
RATE
PACKAGING
CODE
RESISTANCE TOLERANCE AND MULTIPLIERS
TOLERANCE
MULTIPLIER
VALUE
RANGE ()
± 1 % ± 2 % ± 5 % ± 10 %
DG J M 1 1 to 9xx
E H K N 1000 1K to 9xxK
F T L P 1 000 000 1M to 22M
Examples: 11D3 = 11.3 ± 1 %
10E0 = 10 k ± 1 %
332D = 332 ± 1 %
2F21 = 2.21 M ± 1 %
51G0 = 51 ± 2 %
10H0 = 10 k ± 2 %
33H0 = 33 k ± 2 %
22T0 = 22 M ± 2 %
15J0 = 15 ± 5 %
10K0 = 10 k ± 5 %
560K = 560 k ± 5 %
8L20 = 8.2 M ± 5 %
10M0 = 10 ± 10 %
10N0 = 10 k ± 10 %
2P70 = 2.7 M ± 10 %
8P20 = 8.2 M ± 10 %
55342M02M B10E0R W B
