DRV8301-69M-KIT 其他数据使用手册 - TI（德州仪器）

制造商:

TI（德州仪器）

分类:

开发套件

描述:

3 相无刷式直流和永磁同步电动机套件，带 TMS320F28069MDRV8301-69M-KIT 是受 C2000™ InstaSPIN™ TMS320F28069M 微控制器支持的 60V、40A 连续三相反相器平台，采用 InstaSPIN-FOC 和 InstaSPIN MOTION 技术，装在只读存储器中。开发人员可以快速识别、自动调谐和控制三相电动机，同时提供一个即时稳定和功能正常的电动机控制系统。DRV8301 3 相无刷电机预驱动器，带双电流感应放大器和降压转换器 Code Composer Studio 集成开发环境 (IDE) ### 套件包含controlCARD 基于 C2000 InstaSPIN TMS320F28069M 微控制器 USB 电缆 USB 棒，带 GUI 软件、Code Composer Studio IDE 和快速入门指南 ### 电动机控制器和驱动器，Texas Instruments

Pictures:

3D模型

符号图

焊盘图

引脚图

产品图

页面导航:

应用领域在P1

查看文档

1 应用领域

查看文档

导航目录

应用领域在P1

DRV8301-69M-KIT数据手册

Page:

of 2 Go

PDF下载

若手册格式错乱，请下载阅览PDF原文件

  TI Home >   Semiconductors >   Microcontrollers >   Three Phase BLDC & PMSM Motor Kit with DRV8301 and InstaSPIN-enabled Piccolo TMS320F28069M MCU
 Worldwide (In English)
(ACTIVE) DRV8301-69M-KIT
Three Phase BLDC & PMSM Motor Kit with DRV8301 and InstaSPIN-enabled
Piccolo TMS320F28069M MCU
Description
& Features
Technical
Documents
Support &
Community
Order
Now
Description
The DRV8301-69M-KIT is a 60V, 40A continuous, three phase inverter platform enabled by the Piccolo
TMS320F28069M MCU with InstaSPIN-FOC and InstaSPIN-MOTION software in ROM. The kit is ideal for spinning
three phase brushless DC and brushless AC (BLAC) motors – often referred to as permanent magnet synchronous
(PMSM) motors. Utilizing Texas Instruments’ new InstaSPIN-FOC and InstaSPIN-MOTION technologies, the
DRV8301-69M-KIT allows developers to quickly identify, automatically tune, and control a three phase motor,
providing an “instantly” stable and functional motor control system.
Features
DRV8301 2.3A sink/1.7A source, three phase inverter with integrated buck converter for 1.5A external loads.
C2000 Piccolo TMS320F28069M MCU controlCARD with Isolated XDS100v2 JTAG Emulation
CCS Integrated Development Environment (IDE)
Kit supports 60V and 40A full scale range
All documentation, software and user's guides available for free through MotorWare at www.ti.com/tool/motorware
What's Included
Piccolo Isolated F28069M controlCARD
USB Cable
USB Stick with GUI, CCStudio IDE, and Quick Start Guide
NO wall power supply, provide your own high current supply
NO Motor! – Instantly identify and spin YOUR motor with InstaSPIN-FOC and InstaSPIN-MOTION
Latest USB contents for the motor kits here.
See MotorWare™ for latest installation of all software and documentation
InstaSPIN Simulation Tool
Start your FREE interactive simulation now for 3-phase motor control InstaSPIN-FOC
and FAST software sensor enabled devices.
more

Order Now

Part Number Buy from Texas Instruments Buy from Authorized Distributor Status
DRV8301-69M-KIT:
Three Phase BLDC & PMSM Motor Kit with DRV8301 and InstaSPIN-enabled Piccolo TMS320F28069M MCU
$299.00(US$)
In Stock
Ships in 24 to 48 hours
Buy from TI
Pricing may vary.
Buy from distributor
ACTIVE
Contact a Distributor
United States

Go
Technical Documents
Datasheet (1)
Title Abstract Type Size (KB) Date Views
TMS320F2806x Piccolo Microcontrollers (Rev. D) PDF 1915 20 Dec 2012
User Guides (4)
Title Abstract Type Size (KB) Date Views
TMS320F2802xF/F2806xF/M InstaSPIN-FOC/MOTION User's Guide (Rev. B) PDF 37875 11 Sep 2013 7,391
InstaSPIN SIM User’s Guide Read Abstract PDF 1550 14 Jun 2013 2,407
TMS320F2806xM InstaSPIN-MOTION Technical Reference Manual Read Abstract PDF 5900 18 Apr 2013 5,202
TMS320F2806xF InstaSPIN-FOC Software Technical Reference Manual Read Abstract PDF 492 26 Feb 2013 6,035
More Literature (1)
Title Abstract Type Size (KB) Date Views
Breakthrough InstaSPIN™-FOC motor control technology is here PDF 216 17 Oct 2012 3,925
Related Products
Software (4)
Show More
Development Tools (1)
Name Part Number Tool Type
InstaSPIN™ Simulation Tool  INSTASPINSIM  Circuit Design & Simulation
Name Part Number Software Type
controlSUITE  CONTROLSUITE  Software Libraries
Motor Kit Application Software for TMDSCNCD28069MISO controlCARDs  MOTORKITSCNCD69MISO  Application Software & Frameworks
MotorWare™ Software  MOTORWARE  Application Software & Frameworks
