1 of 2 111203
DS1402X
1-Wire Network Cables
www.maxim-ic.com
FEATURES
§ Coiled cables to connect iButtons
®
to 1-Wire
®
networks
§ Convenient, off-the-shelf connectivity
§ Blue Dot Dual Receptors for momentary
(F3/F5 MicroCan) or dwelled contact (F5
MicroCan only) with adhesive pad to mount
on objects (DS1402D-DB8, DS1402D-DR8,
each 2.4m max.)
§ Touch-and-Hold Probes DS1402BP8 and
DS1402RP8 for momentary touch (F3/F5
MicroCan) or dwelled contact (F5 MicroCan
only) in 2.4m length max.
§ iButton cable (DS1402BR8) to connect
DS1401 iButton Holder to USB or serial port
1-Wire adapters.
§ Can be used with any Dallas Semiconductor
port adapter
ORDERING INFORMATION
DS1402D-DB8 2.4m (8ft) cable
DS1402D-DR8 2.4m (8ft) cable
DS1402BP8 2.4m (8ft) cable
DS1402RP8 2.4m (8ft) cable
DS1402BR8 2.4m (8ft) cable
DESCRIPTION
Using four basic types of connectors, 1-Wire RJ-11, iButton, Touch-and-Hold Probe, and Blue Dot
Receptor, the DS1402 series of 1-Wire network cables provides connectivity for iButtons. The cables are
designed to connect any USB, serial, or parallel port 1-Wire adapter to any iButton. Both, the iButton
probe cables and the Blue Dot receptor cables can touch any iButton, but can only hold the F5 version
iButtons. The DS1402BR8 is the only cable that connects to the DS1401 iButton Holder. Applications of
the DS1402-series 1-Wire network cables range from software protection and access control to asset
management and thermal monitoring through handheld computers.
Connectivity Matrix
Cable Part Number Connects From To
DS1402D-DB8
Blue Dot Receptor Cable
DS1410E, DS1411, DS1413,
any version or DS1401
any iButton
DS1402D-DR8
Blue Dot Receptor Cable
DS9490R, DS9097U (any
version), DS9097, DS9097E
any iButton
DS1402BP8
iButton Probe Cable
DS1410E, DS1411, DS1413,
any version or DS1401
any iButton
DS1402RP8
iButton Probe Cable
DS9490R, DS9097U (any
version), DS9097, DS9097E
any iButton
DS1402BR8 DS9490R, DS9097U (any
version), DS9097, DS9097E
DS1401
Front Panel iButton Holder
iButton and 1-Wire are registered trademarks of Dallas Semiconductor.
