Precision Analog Microcontroller, 14-Bit Analog
I/O with MDIO Interface, ARM Cortex-M3
Data Sheet
ADuCM320i
FEATURES
Analog input/output
Multichannel, 14-bit, 1 MSPS analog-to-digital
converter (ADC)
Up to 16 ADC input channels
0 V to V
REF
analog input range
Fully differential and single-ended modes
AV
DD
and IOV
DD
monitors
12-bit voltage output digital-to-analog converters (VDACs)
8 VDACs with a range of 0 V to 2.5 V or AV
DD
outputs
12-bit current output DACs (IDACs)
4 IDACS with a range of 0 mA to 150 mA outputs
Voltage comparator
Microcontroller
ARM Cortex-M3 processor, 32-bit RISC architecture
Serial wire port supports code download and debug
Clocking options
80 MHz PLL with programmable divider
Trimmed on-chip oscillator (±3%)
External 16 MHz crystal option
External clock source up to 80 MHz
Memory
2 × 128 kB independent Flash/EE memories
10,000 cycle Flash/EE endurance
20-year Flash/EE retention
32 kB SRAM
In circuit reprogrammability via I
2
C
On-chip peripherals
MDIO slave up to 4 MHz
2 × I
2
C, 2 × SPI, UART
Multiple general-purpose input/output (GPIO) pins: 3.6 V
compliant
7 × 1.2 V compatible when used for MDIO
32-element programmable logic array (PLA)
3 general-purpose timers
Wake-up timer
Watchdog timer
16-bit pulse width modulator (PWM)
Power
Supply range: 2.9 V to 3.6 V, and 1.8 V to 2.5 V for IDACs
Flexible operating modes for low power applications
Package and temperature range
6 mm × 6mm, 96-ball CSP_BGA package
Fully specified for −40°C to +85°C ambient operation
Tools
Low cost QuickStart development system
Full third party support
APPLICATIONS
Optical networking
Rev. 0
Document Feedback
Information furnished by Analog Devices is believed to be accurate and reliable. However, no
responsibility is assumed by Analog Devices for its use, nor for any infringements of patents or other
rights of third parties that may result from its use. Specifications subject to change without notice. No
license is granted by implication or otherwise under any patent or patent rights of Analog Devices.
Trademarks and registered trademarks are the property of their respective owners.
One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.
Tel: 781.329.4700 ©2015 Analog Devices, Inc. All rights reserved.
Technical Support www.analog.com
