DSA90C200HR
Low Loss and Soft Recovery
High Performance Schottky Diode
Common Cathode
Schottky Diode Gen ²
1 2 3
Part number
DSA90C200HR
Backside: isolated
FAV
F
VV0.79
RRM
45
200
=
V= V
I= A
2x
Features / Advantages: Applications: Package:
● Very low Vf
● Extremely low switching losses
● Low Irm values
● Improved thermal behaviour
● High reliability circuit operation
● Low voltage peaks for reduced
protection circuits
● Low noise switching
● Rectifiers in switch mode power
supplies (SMPS)
● Free wheeling diode in low voltage
converters
ISO247
● Industry standard outline
● RoHS compliant
● Epoxy meets UL 94V-0
● Soldering pins for PCB mounting
● Backside: DCB ceramic
● Reduced weight
● Advanced power cycling
● Isolation Voltage: V~
3600
IXYS reserves the right to change limits, conditions and dimensions.
20130909bData according to IEC 60747and per semiconductor unless otherwise specified
© 2013 IXYS all rights reserved
