dsPIC30F4011/4012
DS70135C-page 2 Preliminary 2005 Microchip Technology Inc.
Analog Features:
• 10-bit Analog-to-Digital Converter (A/D) with
4 S/H Inputs:
- 500 Ksps conversion rate
- 9 input channels
- Conversion available during Sleep and Idle
• Programmable Brown-out Detection and Reset
generation
Special Microcontroller Features:
• Enhanced Flash program memory:
- 10,000 erase/write cycle (min.) for
industrial temperature range, 100K (typical)
• Data EEPROM memory:
- 100,000 erase/write cycle (min.) for
industrial temperature range, 1M (typical)
• Self-reprogrammable under software control
• Power-on Reset (POR), Power-up Timer (PWRT)
and Oscillator Start-up Timer (OST)
• Flexible Watchdog Timer (WDT) with on-chip low
power RC oscillator for reliable operation
• Fail-Safe clock monitor operation detects clock
failure and switches to on-chip low power RC
oscillator
• Programmable code protection
• In-Circuit Serial Programming™ (ICSP™)
• Selectable Power Management modes
- Sleep, Idle and Alternate Clock modes
CMOS Technology:
• Low power, high speed Flash technology
• Wide operating voltage range (2.5V to 5.5V)
• Industrial and Extended temperature ranges
• Low power consumption
dsPIC30F Motor Control and Power Conversion Family*
Device Pins
Program
Mem. Bytes/
Instructions
SRAM
Bytes
EEPROM
Bytes
Timer
16-bit
Input
Cap
Output
Comp/Std
PWM
Moto
Control
PWM
A/D 10-bit
500 Ksps
Quad
Enc
UART
SPI
™
I
2
C™
CAN
dsPIC30F2010 28 12K/4K 512 1024 3 4 2 6 ch 6 ch Yes 1 1 1 -
dsPIC30F3010 28 24K/8K 1024 1024 5 4 2 6 ch 6 ch Yes 1 1 1 -
dsPIC30F4012 28 48K/16K 2048 1024 5 4 2 6 ch 6 ch Yes 1 1 1 1
dsPIC30F3011 40/44 24K/8K 1024 1024 5 4 4 6 ch 9 ch Yes 2 1 1 -
dsPIC30F4011 40/44 48K/16K 2048 1024 5 4 4 6 ch 9 ch Yes 2 1 1 1
dsPIC30F5015 64 66K/22K 2048 1024 5 4 4 8 ch 16 ch Yes 1 2 1 1
dsPIC30F6010 80 144K/48K 8192 4096 5 8 8 8 ch 16 ch Yes 2 2 1 2
* This table provides a summary of the dsPIC30F6010 peripheral features. Other available devices in the dsPIC30F
Motor Control and Power Conversion Family are shown for feature comparison.
