2011-2015 Microchip Technology Inc. DS80000526F-page 1
dsPIC33EPXXX(GP/MC/MU)806/810/814
and PIC24EPXXX(GP/GU)810/814
The dsPIC33EPXXX(GP/MC/MU)806/810/814 and
PIC24EPXXX(GP/GU)810/814 family devices that you
have received conform functionally to the current
Device Data Sheet (DS70616G), except for the
anomalies described in this document.
The silicon issues discussed in the following pages are
for silicon revisions with the Device and Revision IDs
listed in Table 1. The silicon issues are summarized in
Table 2.
The errata described in this document will be addressed
in future revisions of the dsPIC33EPXXX(GP/MC/
MU)806/810/814 and PIC24EPXXX(GP/GU)810/814
silicon.
Data Sheet clarifications and corrections start on
page 15, following the discussion of silicon issues.
The silicon revision level can be identified using the
current version of MPLAB
®
IDE and Microchip’s
programmers, debuggers and emulation tools, which
are available at the Microchip corporate web site
(www.microchip.com).
For example, to identify the silicon revision level using
MPLAB IDE in conjunction with MPLAB ICD 3 or
PICkit™ 3:
1. Using the appropriate interface, connect the device
to the MPLAB ICD 3 programmer/debugger or
PICkit 3.
2. From the main menu in MPLAB IDE, select
Configure>Select Device
, and then select the
target part number in the dialog box.
3. Select the MPLAB hardware tool
(Debugger>Select Tool
).
4. Perform a “Connect” operation to the device
(Debugger>Connect
). Depending on the devel-
opment tool used, the part number and Device
Revision ID value appear in the Output window.
The Device and Revision ID values for the
various dsPIC33EPXXX(GP/MC/MU)806/810/814
and PIC24EPXXX(GP/GU)810/814 silicon revisions
are shown in Tabl e 1 .
Note: This document summarizes all silicon
errata issues from all revisions of silicon,
previous as well as current. Only the
issues indicated in the last column of
Table 2 apply to the current silicon
revision (B1).
Note: If you are unable to extract the silicon
revision level, please contact your local
Microchip sales office for assistance.
TABLE 1: SILICON DEVREV VALUES
Part Number Device ID
(1)
Revision ID for Silicon Revision
(2)
B1
dsPIC33EP256MU806 0x1861
0x4002
dsPIC33EP256MU810 0x1862
dsPIC33EP256MU814 0x1863
PIC24EP256GU810 0x1826
PIC24EP256GU814 0x1827
dsPIC33EP512MU810 0x1872
dsPIC33EP512MU814 0x1873
dsPIC33EP512GP806 0x187D
dsPIC33EP512MC806 0x1879
Note 1: The Device and Revision IDs (DEVID and DEVREV) are located at the last two implemented addresses in
program memory.
2: Refer to the “dsPIC33E/PIC24E Flash Programming Specification” (DS70619) for detailed information on
Device and Revision IDs for your specific device.
dsPIC33EPXXX(GP/MC/MU)806/810/814 and PIC24EPXXX(GP/GU)810/814
Family Silicon Errata and Data Sheet Clarification
