Design and specifi cations are each subject to change without notice. Ask factory for the current technical specifi cations before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
Aluminum Electrolytic Capacitors/ NHG
– EEE-101 –
■ Standard Prod ucts
W.V.
Cap.
(±20 %)
Case size Specifi cation Lead Length
Part No.
Min. Packaging Q'ty
Dia. Length
Ripple
Current
(120 Hz)
(+105 °C)
tan
δ
(120 Hz)
(+20 °C)
Endur-
ance
Lead
Dia.
Lead Space
Straight
Leads
Taping
Straight
Taping
✽
B
Taping
✽
i
(V) (µF) (mm) (mm)
(mA r.m.s.)
(hours) (mm) (mm) (mm) (mm) (pcs) (pcs)
50
0.1 5 11 1.1 0.12 1000 0.5 2.0 5.0 2.5
ECA1HHG0R1( )
200 2000
0.22 5 11 2.3 0.12 1000 0.5 2.0 5.0 2.5
ECA1HHGR22( )
200 2000
0.33 5 11 3.5 0.12 1000 0.5 2.0 5.0 2.5
ECA1HHGR33( )
200 2000
0.47 5 11 5 0.12 1000 0.5 2.0 5.0 2.5
ECA1HHGR47( )
200 2000
15 11 100.121000 0.5 2.0 5.0 2.5
ECA1HHG010( )
200 2000
2.2 5 11 18 0.12 1000 0.5 2.0 5.0 2.5
ECA1HHG2R2( )
200 2000
3.3 5 11 22 0.12 1000 0.5 2.0 5.0 2.5
ECA1HHG3R3( )
200 2000
4.7 5 11 26 0.12 1000 0.5 2.0 5.0 2.5
ECA1HHG4R7( )
200 2000
10 5 11 39 0.121000 0.5 2.0 5.0 2.5
ECA1HHG100( )
200 2000
22 5 11 65 0.121000 0.5 2.0 5.0 2.5
ECA1HHG220( )
200 2000
33 5 11 90 0.121000 0.5 2.0 5.0 2.5
ECA1HHG330( )
200 2000
47 6.3 11.2 110 0.12 1000 0.5 2.5 5.0 2.5
ECA1HHG470( )
200 2000
100 8 11.5 180 0.121000 0.6 3.5 5.0
ECA1HHG101( )
200 1000
220 10 12.5 300 0.12 2000 0.6 5.0 5.0
ECA1HHG221( )
200 500
330 10 16 410 0.12 2000 0.6 5.0 5.0
ECA1HHG331( )
200 500
470 10 20 530 0.12 2000 0.6 5.0 5.0
ECA1HHG471( )
200 500
1000 12.5 25 950 0.12 2000 0.6 5.0 5.0
ECA1HHG102( )
200 500
2200 16 31.5 1470 0.14 2000 0.8 7.5
ECA1HHG222
100
3300 18 35.5 1770 0.16 2000 0.8 7.5
ECA1HHG332
50
63
10 5 11 46 0.101000 0.5 2.0 5.0 2.5
ECA1JHG100( )
200 2000
22 5 11 71 0.101000 0.5 2.0 5.0 2.5
ECA1JHG220( )
200 2000
33 6.3 11.2 100 0.10 1000 0.5 2.5 5.0 2.5
ECA1JHG330( )
200 2000
47 6.3 11.2 120 0.10 1000 0.5 2.5 5.0 2.5
ECA1JHG470( )
200 2000
100 10 12.5 215 0.10 2000 0.6 5.0 5.0
ECA1JHG101( )
200 500
220 10 16 335 0.10 2000 0.6 5.0 5.0
ECA1JHG221( )
200 500
330 10 20 510 0.10 2000 0.6 5.0 5.0
ECA1JHG331( )
200 500
470 12.5 20 640 0.10 2000 0.6 5.0 5.0
ECA1JHG471( )
200 500
1000 16 25 930 0.10 2000 0.8 7.5 7.5
ECA1JHG102( )
100 250
2200 18 35.5 1610 0.12 2000 0.8 7.5
ECA1JHG222
50
100
0.47 5 11 9 0.08 1000 0.5 2.0 5.0 2.5
ECA2AHGR47( )
200 2000
15 11 140.08 1000 0.5 2.0 5.0 2.5
ECA2AHG010( )
200 2000
2.2 5 11 21 0.08 1000 0.5 2.0 5.0 2.5
ECA2AHG2R2( )
200 2000
3.3 5 11 31 0.08 1000 0.5 2.0 5.0 2.5
ECA2AHG3R3( )
200 2000
4.7 5 11 38 0.08 1000 0.5 2.0 5.0 2.5
ECA2AHG4R7( )
200 2000
10 6.3 11.2 54 0.08 1000 0.5 2.5 5.0 2.5
ECA2AHG100( )
200 2000
22 6.3 11.2 93 0.08 1000 0.5 2.5 5.0 2.5
ECA2AHG220( )
200 2000
· When requesting taped product, please put the letter "B" or "i" between the "( )". Lead wire pitch B=5 mm, 7.5 mm, i=2.5 mm.
