Aluminum Electrolytic Capacitors (Radial Lead Type)
Characteristics list
Endurance : 85 °C 1000 h
Rated
voltage
(V.DC)
Cap.
(±20 %)
(µF)
Case size (mm)
Specifi cation
Lead length (mm)
Part No.
Min. Packaging Q'ty
0
DL
Ripple
current
(120 Hz)
(+85 °C)
(mA r.m.s.)
tan
d
(120 Hz)
(+20 °C)
Lead
dia.
0
d
Lead space
Straight
leads
(pcs)
Taping
(pcs)
Straight
Taping
✽
B
Taping
✽
i
4
47 4 7 34 0.35 0.45 1.5 5.0 2.5 ECEA0GKA470( ) 200 2000
100 5 7 61 0.35 0.45 2.0 5.0 2.5 ECEA0GKA101( ) 200 2000
220 6.3 7 82 0.35 0.45 2.5 5.0 2.5 ECEA0GKA221( ) 200 2000
330
871100.350.452.5 2.5ECEA0GKA331( ) 200 1000
871100.350.45 5.0 ECEA0GKA331Q 1000
470
871400.350.452.5 2.5ECEA0GKA471( ) 200 1000
871400.350.45 5.0 ECEA0GKA471Q 1000
6.3
47 4 7 46 0.24 0.45 1.5 5.0 2.5 ECEA0JKA470( ) 200 2000
100 5 7 71 0.24 0.45 2.0 5.0 2.5 ECEA0JKA101( ) 200 2000
220 6.3 7 103 0.24 0.45 2.5 5.0 2.5 ECEA0JKA221( ) 200 2000
330
871300.240.452.5 2.5ECEA0JKA331( ) 200 1000
871300.240.45 5.0 ECEA0JKA331Q 1000
10
33 4 7 43 0.20 0.45 1.5 5.0 2.5 ECEA1AKA330( ) 200 2000
100 6.3 7 80 0.20 0.45 2.5 5.0 2.5 ECEA1AKA101( ) 200 2000
220
871200.200.452.5 2.5ECEA1AKA221( ) 200 1000
871200.200.45 5.0 ECEA1AKA221Q 1000
16
10 4 7 28 0.16 0.45 1.5 5.0 2.5 ECEA1CKA100( ) 200 2000
22 4 7 39 0.16 0.45 1.5 5.0 2.5 ECEA1CKA220( ) 200 2000
33 5 7 60 0.16 0.45 2.0 5.0 2.5 ECEA1CKA330( ) 200 2000
47 5 7 70 0.16 0.45 2.0 5.0 2.5 ECEA1CKA470( ) 200 2000
100 6.3 7 91 0.16 0.45 2.5 5.0 2.5 ECEA1CKA101( ) 200 2000
25
10 4 7 28 0.14 0.45 1.5 5.0 2.5 ECEA1EKA100( ) 200 2000
22 5 7 55 0.14 0.45 2.0 5.0 2.5 ECEA1EKA220( ) 200 2000
33 6.3 7 65 0.14 0.45 2.5 5.0 2.5 ECEA1EKA330( ) 200 2000
47 6.3 7 70 0.14 0.45 2.5 5.0 2.5 ECEA1EKA470( ) 200 2000
35
10 5 7 30 0.12 0.45 2.0 5.0 2.5 ECEA1VKA100( ) 200 2000
22 6.3 7 60 0.12 0.45 2.5 5.0 2.5 ECEA1VKA220( ) 200 2000
33 6.3 7 65 0.12 0.45 2.5 5.0 2.5 ECEA1VKA330( ) 200 2000
47
8 7 85 0.12 0.45 2.5 2.5 ECEA1VKA470( ) 200 1000
8 7 85 0.12 0.45 5.0 ECEA1VKA470Q 1000
50
2.2 4 7 16 0.10 0.45 1.5 5.0 2.5 ECEA1HKA2R2( ) 200 2000
3.3 4 7 18 0.10 0.45 1.5 5.0 2.5 ECEA1HKA3R3( ) 200 2000
4.7 4 7 23 0.10 0.45 1.5 5.0 2.5 ECEA1HKA4R7( ) 200 2000
10 5 7 35 0.10 0.45 2.0 5.0 2.5 ECEA1HKA100( ) 200 2000
22 6.3 7 60 0.10 0.45 2.5 5.0 2.5 ECEA1HKA220( ) 200 2000
33
8 7 75 0.10 0.45 2.5 2.5 ECEA1HKA330( ) 200 1000
8 7 75 0.10 0.45 5.0 ECEA1HKA330Q 1000
· When requesting taped product, please put the letter “B” or “i” between the “( )”. Lead wire pitch
✽
B=5 mm, i=2.5 mm.
· Please refer to the page of “Taping dimensions”.
