Aluminum Electrolytic Capacitors (SMD Type)
Endurance : 105 °C 1000 h
Rated
voltage
(V.DC)
Cap.
(±20 %)
(µF)
Case size (mm)
Size
code
Specifi cation
Part No. Refl ow
Min. Packaging Q'ty
0
DL
Ripple
current
(100 kHz)
(+105 °C)
(mA r.m.s.)
Impedance
(100 kHz)
(+20 °C)
(Ω)
tan
d
(120 Hz)
(+20 °C)
Taping
(pcs)
6.3
22 4 5.4 B 60 3.00 0.26 EEEFC0J220AR (5) 2000
47 5 5.4 C 95 1.80 0.26 EEEFC0J470AR (5) 1000
68 6.3 5.4 D 140 1.00 0.26 EEEFC0J680AP (5) 1000
100 6.3 5.4 D 140 1.00 0.26 EEEFC0J101AP (5) 1000
220 8 6.2 E 230 0.40 0.26 EEEFC0J221AP (6) 1000
330 8 10.2 F 450 0.30 0.26 EEEFC0J331AP (6) 500
1000 10 10.2 G 670 0.15 0.26 EEEFC0J102AP (6) 500
1500 10 10.2 G 670 0.15 0.26 EEEFC0J152AP (6) 500
10
33 5 5.4 C 95 1.80 0.19 EEEFC1A330AR (5) 1000
100 8 6.2 E 230 0.40 0.19 EEEFC1A101AP (6) 1000
150 8 6.2 E 230 0.40 0.19 EEEFC1A151AP (6) 1000
220 8 10.2 F 450 0.30 0.19 EEEFC1A221AP (6) 500
470 10 10. 2 G 670 0.15 0.19 EEEFC1A471AP (6) 500
1000 10 10.2 G 670 0.15 0.19 EEEFC1A102AP (6) 500
16
10 4 5.4 B 60 3.00 0.16 EEEFC1C100AR (5) 2000
22 5 5.4 C 95 1.80 0.16 EEEFC1C220AR (5) 1000
47 6.3 5.4 D 140 1.00 0.16 EEEFC1C470AP (5) 1000
68 8 6.2 E 230 0.40 0.16 EEEFC1C680AP (6) 1000
100 8 6.2 E 230 0.40 0.16 EEEFC1C101AP (6) 1000
22 0 10 10 . 2 G 670 0.15 0.16 EEEFC1C221AP (6) 500
3 3 0 10 10. 2 G 670 0 .15 0 .16 EEEFC1C331AP (6) 500
470 10 10. 2 G 670 0.15 0.16 EEEFC1C471AP (6) 500
6 8 0 10 10 . 2 G 670 0.15 0.16 EEEFC1C681AP (6) 500
25
6.8 4 5.4 B 60 3.00 0.14 EEEFC1E6R8AR (5) 2000
22 6.3 5.4 D 140 1.00 0.14 EEEFC1E220AP (5) 1000
33 6.3 5.4 D 140 1.00 0.14 EEEFC1E330AP (5) 1000
47 8 6.2 E 230 0.40 0.14 EEEFC1E470AP (6) 1000
68 8 10.2 F 450 0.30 0.14 EEEFC1E680AP (6) 500
100 8 10.2 F 450 0.30 0.14 EEEFC1E101AP (6) 500
22 0 10 10 . 2 G 670 0.15 0 .14 EEEFC1E221AP (6) 500
3 3 0 10 10. 2 G 670 0 .15 0.14 EEEFC1E331AP (6) 500
470 10 10. 2 G 670 0.15 0.14 EEEFC1E471AP (6) 500
35
14 5.4B 603.000.12EEEFC1V1R0AR (5) 2000
2.2 4 5.4 B 60 3.00 0.12 EEEFC1V2R2AR (5) 2000
3.3 4 5.4 B 60 3.00 0.12 EEEFC1V3R3AR (5) 2000
4.7 4 5.4 B 60 3.00 0.12 EEEFC1V4R7AR (5) 2000
6.8 5 5.4 C 95 1.80 0.12 EEEFC1V6R8AR (5) 1000
10 5 5.4 C 95 1.80 0.12 EEEFC1V100AR (5) 1000
22 6.3 5.4 D 140 1.00 0.12 EEEFC1V220AP (5) 1000
33 8 6.2 E 230 0.40 0.12 EEEFC1V330AP (6) 1000
47 8 6.2 E 230 0.40 0.12 EEEFC1V470AP (6) 1000
10 0 10 10.2 G 670 0 .15 0 .12 EEEFC1V101AP (6) 500
22 0 10 10 . 2 G 670 0.15 0 .12 EEEFC1V221AP (6) 500
3 3 0 10 10. 2 G 670 0 .15 0 .12 EEEFC1V331AP (6) 500
· Please refer to the page of “Refl ow Profi le” and “The Taping Dimensions”.
· When requesting vibration-proof product, please put the last “V” instead to “P”
Characteristics list
Mar. 201602
