Design and specifi cations are each subject to change without notice. Ask factory for the current technical specifi cations before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
Aluminum Electrolytic Capacitors/ FK
– EEE-42 –
■ Standard Prod ucts
W.V.
Cap.
(±20 %)
Case size Specifi cation
Part No.
(RoHS:compliant)
Refl ow
Min.
Packaging Q'ty
Dia. Length
✽
Size
Code
Ripple
Current
(100 kHz)
(+105 °C)
Impedance
(100 kHz)
(+20 °C)
tan
d
(120 Hz)
(+20 °C)
Taping
(V) (μF) (mm) (mm)
(mA r.m.s.)
(Ω)(pcs)
6.3
22 4 5.8 B 90 1.35 0.26 EEEFK0J220R (1) 2000
47
45.8(B)901.350.26EEEFK0J470UR (1) 2000
5 5.8 C 160 0.70 0.26 EEEFK0J470R (1) 1000
100
5 5.8 (C) 160 0.70 0.26 EEEFK0J101UR (1) 1000
6.3 5.8 D 240 0.36 0.26 EEEFK0J101P (1) 1000
220 6.3 5.8 D 240 0.36 0.26 EEEFK0J221P (1) 1000
330
6.3 7.7 D8 280 0.34 0.26 EEEFK0J331XP (1) 900
8 6.2 E 300 0.26 0.26 EEEFK0J331P (2) 1000
470 8 10.2 F 600 0.16 0.26 EEEFK0J471P (2) 500
1000 8 10.2 F 600 0.16 0.26 EEEFK0J102P (2) 500
1500 10 10.2 G 850 0.08 0.26 EEEFK0J152P (2) 500
3300 12.5 13.5 H13 1100 0.06 0.30 EEVFK0J332Q (3) 200
6800 16 16.5 J16 1800 0.035 0.36 EEVFK0J682M (3) 125
10
22 4 5.8 B 90 1.35 0.19 EEEFK1A220R (1) 2000
33
45.8(B)901.350.19EEEFK1A330UR (1) 2000
5 5.8 C 160 0.70 0.19 EEEFK1A330R (1) 1000
150 6.3 5.8 D 240 0.36 0.19 EEEFK1A151P (1) 1000
220
6.3 7.7 D8 280 0.34 0.19 EEEFK1A221XP (1) 900
8 6.2 E 300 0.26 0.19 EEEFK1A221P (2) 1000
330 8 10.2 F 600 0.16 0.19 EEEFK1A331P (2) 500
470 8 10.2 F 600 0.16 0.19 EEEFK1A471P (2) 500
680 8 10.2 F 600 0.16 0.19 EEEFK1A681P (2) 500
1000 10 10.2 G 850 0.08 0.19 EEEFK1A102P (2) 500
2200 12.5 13.5 H13 1100 0.06 0.21 EEVFK1A222Q (3) 200
4700 16 16.5 J16 1800 0.035 0.25 EEVFK1A472M (3) 125
6800 18 16.5 K16 2060 0.033 0.29 EEVFK1A682M (3) 125
16
10 4 5.8 B 90 1.35 0.16 EEEFK1C100R (1) 2000
22
45.8(B)901.350.16EEEFK1C220UR (1) 2000
5 5.8 C 160 0.70 0.16 EEEFK1C220R (1) 1000
47
5 5.8 (C) 160 0.70 0.16
EEEFK1C470UR (1) 1000
6.3 5.8 D 240 0.36 0.16 EEEFK1C470P (1) 1000
68 6.3 5.8 D 240 0.36 0.16 EEEFK1C680P (1) 1000
100 6.3 5.8 D 240 0.36 0.16 EEEFK1C101P (1) 1000
150 6.3 7.7 D8 280 0.34 0.16 EEEFK1C151XP (1) 90 0
220
6.3 7.7 D8 280 0.34 0.16 EEEFK1C221XP (1) 900
8 6.2 E 300 0.26 0.16 EEEFK1C221P (2) 1000
330 8 10.2 F 600 0.16 0.16 EEEFK1C331P (2) 500
470 8 10.2 F 600 0.16 0.16 EEEFK1C471P (2) 500
680 10 10.2 G 850 0.08 0.16 EEEFK1C681P (2) 500
1500 12.5 13.5 H13 1100 0.06 0.16 EEVFK1C152Q (3) 200
3300 16 16.5 J16 1800 0.035 0.20 EEVFK1C332M (3) 125
4700 18 16.5 K16 2060 0.033 0.22 EEVFK1C472M (3) 125
25
10 4 5.8 B 90 1.35 0.14 EEEFK1E100R (1) 2000
22 5 5.8 C 160 0.70 0.14 EEEFK1E220R (1) 1000
33
5 5.8 (C) 160 0.70 0.14 EEEFK1E330UR (1) 1000
6.3 5.8 D 240 0.36 0.14 EEEFK1E330P (1) 1000
47 6.3 5.8 D 240 0.36 0.14 EEEFK1E470P (1) 1000
68 6.3 5.8 D 240 0.36 0.14 EEEFK1E680P (1) 1000
100
6.3 7.7 D8 280 0.34 0.14 EEEFK1E101XP (1) 9 00
8 6.2 E 300 0.26 0.14 EEEFK1E101P (2) 1000
150 8 10.2 F 600 0.16 0.14 EEEFK1E151P (2) 500
220 8 10.2 F 600 0.16 0.14 EEEFK1E221P (2) 500
330 8 10.2 F 600 0.16 0.14 EEEFK1E331P (2) 500
470 10 10.2 G 850 0.08 0.14 EEEFK1E471P (2) 500
1000 12.5 13.5 H13 1100 0.06 0.14 EEVFK1E102Q (3) 200
1500 16 16.5 J16 1800 0.035 0.14 EEVFK1E152M (3) 125
2200 16 16.5 J16 1800 0.035 0.16 EEVFK1E222M (3) 125
3300 18 16.5 K16 2060 0.033 0.18 EEVFK1E332M (3) 125
✽
Size code( ):Miniaturization product
· Please refer to the page of “Refl ow Profi le” and “The Taping Dimensions”.
· When requesting vibration-proof product, please put the last “V” instead to “P”
Endurance : 105 °C 2000 h (
>
0
12.5 : 5000 h)
01 Mar. 2014
