Aluminum Electrolytic Capacitors
● Endurance：105 ℃ 2000 h to 5000 h
● Miniaturized, Low ESR (1 size smaller than series FK)
● AEC-Q200 compliant
● RoHS compliant
Example：25 V 22 μF
Marking color : BLACK
Unit：mm
・The dimensions of the vibration-proof products, please refer to the page of the mounting specification.
Dissipation factor (tan δ)
Please see the attached characteristics list
Capacitance range
10 μF to 2200 μF
Shelf life
After storage for 1000 hours at +105 ℃ ± 2 ℃ with no voltage applied and then being
(With voltage treatment)
Within the initial limit
Endurance
After applying rated working voltage for 2000 hours at +105 ℃ ± 2 ℃ and then being
stabilized at +20 ℃, capacitors shall meet the following limits.
Rated voltage range
6.3 V to 50 V
Capacitance tolerance
Features
Specifications
Category temp. range
–55 ℃ to +105 ℃
±20 % (120 Hz / +20 ℃)
Leakage current
I ≦ 0.01 CV（μA）After 2 minutes
(Suffix “G” in 6.3 V : 3000 hours, 10 V to 50 V : 5000 hours)
A、B
H
Resistance to
soldering heat
After reflow soldering and then being stabilized at +20 ℃, capacitors shall meet the
Capacitance change
Within ±10 % of the initial value
Dissipation factor（tan δ)
Within the initial limit
Leakage current
Within the initial limit
Marking
10 to 470
560 to 2200
Dimensions
Size code
øD
L
0.70
following limits.
stabilized at +20 ℃, capacitors shall meet the limits specified in endurance.
Frequency correction factor for ripple current
8.3 10.0 max. 3.4 0.90±0.2 3.1
V
Capacitance change
Within ±30 % of the initial value (Suffix “G” is ±35 %)
Dissipation factor（tan δ)
≦ 200 % of the initial limit (Suffix “G” is ≦ 300 %)
Leakage current
4.0 5.8±0.3
Unit：V
j
6.3
0.65±0.1
6.3
0.70±0.2
C
16
1.8
0.35
+0.15
ー0.20
0.65±0.1
1.8
0.35
+0.15
ー0.20
D8
6.3
7.7±0.3
6.6
7.8 max.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
06-Dec-19
10.2±0.3
10.3
12.0 max.
3.5
0.90±0.2
4.6
G
10.0
0.70±0.2
Freq.（Hz)
I
W
P
K
1.5
0.35
0.35
+0.15
ー0.20
+0.15
ー0.20
4.3 5.5 max. 1.8 0.65±0.1 1.0
5.3
6.5 max.
2.2
0.90
0.95
1.00
B
5.8±0.3
6.6
7.8 max.
2.6
2.6
5.8±0.3
R.voltage code
E
25
C
D
35
F 8.0 10.2±0.3
Surface Mount Type
FT series
V
type
High temperature Lead-Free reflow
120 1 k 10 k 100 k to
Cap.（μF）
0.65
0.85
0.95
1.00
A
10
H
50
0.65±0.1
5.0
0.3 max.
øD±0.5
L
H
A±0.2
B±0.2
W
（I）
（P）
（I）
22
E FT
K
Negative polarity marking (–)
Capacitance (μF)
Series identification
Rated voltage code
Lot number
Pressure Relief (ø10 and larger)
（）Reference size
