MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS
ZL
SERIES
ZL
♦SPECIFICATIONS
♦MULTIPLIER FOR RIPPLE CURRENT
Frequency coefficient
•6.3~50WV
Items Characteristics
-40~+105˚C
6.3~100V.DC
±20%(20˚C, 120Hz)
I=0.01CV or 3µA whichever is greater. (After 2 minutes)
I=Leakage Current(µA) C=Nominal Capacitance(µF) V=Rated Voltage(V)
Rated Voltage
(V)
tanδ
0.190.22 0.16
6.3
0.14
10
0.12
16 25 35
0.10
50
0.09
63
0.08
100
Rated Voltage(V)
Z(-25˚C)/Z(20˚C)
6.3 10 16 25
22 222
35
2
Z(-40˚C)/Z(20˚C)
333333
50
2
3
63
2
3
100
Within ±25% of the initial value.
Not more than 200% of the specified value.
Not more than the specified value.
After life test with max. ripple current at conditions stated in the table below, the capacitors shall
meet the following requirements.
JIS C 5141, EIAJ RC-2372
105˚C High ripple current, Low impedance.
♦FEATURES
•
Enabled high ripple current by a reduction of impedance at high
frequency range.
•
Load Life : 105˚C 2000~5000hours.
Freq(Hz)
Cap(µF)
120 1k 10 100k
<
=
0.55 0.75 0.90 1.0022~33
47~330 0.70 0.85 0.95 1.00
470~1000 0.75
60(50)
0.45
0.60
0.65 0.90 0.98 1.00
1200~6800 0.800.75 0.95 1.00 1.00
•63~100WV
Freq(Hz)
Cap(µF)
120 1k 10k 100k
<
-
0.55 0.75 0.90 1.006.8~33
39~330 0.60 0.80 0.95 1.00
390~1500 0.65
60(50)
0.45
0.50
0.55 0.85 0.98 1.00
(20˚C, 120Hz)
(120Hz)
Operating Temperature
Range
Rated Voltage Range
Capacitance Tolerance
Leakage Current(MAX)
Dissipation Factor(MAX)
Load Life
Low Temperature
Stability
Impedance Ratio(MAX)
Reference Standard
Leakage Current
Dissipation Factor
Capacitance Change
Case Dia Life Time(hrs)
2000
3000
4000
5000
When nominal capacitance is over 1000µF, tanδ shall be added 0.02 to the listed value with
increase of every 1000µF.
φD
<
=
6.3
φD=8
φD=10
φD
>
=
12.5
NEW
1 Jun 1999
