EFM32ZG108F8-QFN24数据手册
Page:
of 51 Go
若手册格式错乱，请下载阅览PDF原文件
Preliminary
...the world's most energy friendly microcontrollers
2013-11-22 - EFM32ZG108FXX - d0063_Rev0.61 1
www.silabs.com
EFM32ZG108 DATASHEET
F32/F16/F8/F4
Preliminary
• ARM Cortex-M0+ CPU platform
• High Performance 32-bit processor @ up to 24 MHz
• Wake-up Interrupt Controller
• Flexible Energy Management System
• 20 nA @ 3 V Shutoff Mode
• 0.5 µA @ 3 V Stop Mode, including Power-on Reset, Brown-out
Detector, RAM and CPU retention
• 0.9 µA @ 3 V Deep Sleep Mode, including RTC with 32.768 kHz
oscillator, Power-on Reset, Brown-out Detector, RAM and CPU
retention
• 46 µA/MHz @ 3 V Sleep Mode
• 114 µA/MHz @ 3 V Run Mode, with code executed from flash
• 32/16/8/4 KB Flash
• 4/4/2/2 KB RAM
• 17 General Purpose I/O pins
• Configurable push-pull, open-drain, pull-up/down, input filter, drive
strength
• Configurable peripheral I/O locations
• 11 asynchronous external interrupts
• Output state retention and wake-up from Shutoff Mode
• 4 Channel DMA Controller
• 4 Channel Peripheral Reflex System (PRS) for autonomous in-
ter-peripheral signaling
• Timers/Counters
• 2× 16-bit Timer/Counter
• 2×3 Compare/Capture/PWM channels
• 1× 24-bit Real-Time Counter
• 1× 16-bit Pulse Counter
• Watchdog Timer with dedicated RC oscillator @ 50 nA
• Communication interfaces
• 1× Universal Synchronous/Asynchronous Receiv-
er/Transmitter
• UART/SPI/SmartCard (ISO 7816)/IrDA/I2S
• Triple buffered full/half-duplex operation
• Low Energy UART
• Autonomous operation with DMA in Deep Sleep
Mode
• I
2
C Interface with SMBus support
• Address recognition in Stop Mode
• Ultra low power precision analog peripherals
• 1× Analog Comparator
• Capacitive sensing with up to 2 inputs
• Supply Voltage Comparator
• Ultra efficient Power-on Reset and Brown-Out Detec-
tor
• 2-pin Serial Wire Debug interface
• Pre-Programmed UART Bootloader
• Temperature range -40 to 85 ºC
• Single power supply 1.85 to 3.8 V
• QFN24 package
32-bit ARM Cortex-M0+, Cortex-M3 and Cortex-M4 microcontrollers for:
• Energy, gas, water and smart metering
• Health and fitness applications
• Smart accessories
• Alarm and security systems
• Industrial and home automation
