Altera Corporation 1
DS-S29804-1.1 Preliminary
Data Sheet
Stratix II EP2S60 DSP
Development Board
Features
The Stratix
®
II EP2S60 DSP development board is included with the DSP
Development Kit, Stratix II Edition (ordering code DSP-DEVKIT-2S60).
This board is a development platform for high-performance digital signal
processing (DSP) designs, and features the Stratix II EP2S60 device in a
1020-pin package.
Components
■ Analog I/O
● Two 12-bit 125-MHz A/D converters
● Two 14-bit 165-MHz D/A converters
● One 8-bit, 180 megapixels-per-second triple D/A converter for
VGA output
● One 96-KHz Stereo Audio coder/decoder (CODEC)
■ Memory subsystem
● 1 MByte of 10-ns asynchronous SRAM configured as a 32-bit bus
● 16 MBytes of flash memory configured as an 8-bit bus
● 32 MBytes of SDRAM memory configured as a 64-bit bus
● CompactFlash connector supporting ATA and IDE access modes
■ Configuration options
● On-board configuration using 16 MBytes of flash memory and
an Altera
®
EPM7256 MAX
®
device
● Download configuration data using an USB Blaster
TM
download
cable
■ Single-ended or differential inputs and outputs accessed via a Mictor
connector
■ Dual seven-segment display
■ Four user-defined push-button switches
■ One female 9-pin RS-232 connector
■ 10/100 Ethernet MAC/PHY
■ Eight user-defined LEDs
■ Socketed 100-MHz oscillator
■ Single 16-V DC power supply (adapter included)
■ Active heat sink
May 2005
