Chapter 1: Stratix III Device Family Overview 1–5
Features Summary
© March 2010 Altera Corporation Stratix III Device Handbook, Volume 1
Tab le 1 –4 lists the Stratix III Hybrid FineLine BGA (HBGA) package sizes.
Stratix III devices are available in up to three speed grades: –2, –3, and –4, with –2
being the fastest. Stratix III devices are offered in both commercial and industrial
temperature range ratings with leaded and lead-free packages. Selectable Core
Voltage is available in specially marked low-voltage devices (L ordering code suffix).
Tab le 1 –5 lists the Stratix III device speed grades.
Table 1–4. Hybrid FineLine BGA Package Sizes
Dimension 780 Pin 1152 Pin
Pitch (mm) 1.00 1.00
Area (mm
2
) 1,089 1,600
Length/Width (mmmm) 33/33 40/40
Table 1–5. Speed Grades for Stratix III Devices (Part 1 of 2)
Device
Temperature
Grade
484 -Pin
FineLine
BGA
780-Pin
FineLine
BGA
780-Pin
Hybrid
FineLine
BGA
1152-Pin
FineLine
BGA
1152-Pin
Hybrid
FineLine
BGA
1517-Pin
FineLine
BGA
1760-Pin
FineLine
BGA
EP3SL50
Commercial
–2, –3, –4,
–4L
–2, –3,–4,
–4L
—————
Industrial –3, –4, –4L –3, –4, –4L — — — — —
EP3SL70
Commercial
–2, –3, –4,
–4L
–2, –3, –4,
–4L
—————
Industrial –3, –4, –4L –3, –4, –4L — — — — —
EP3SL110
Commercial —
–2, –3, –4,
–4L
—
–2, –3, –4,
–4L
———
Industrial — –3, –4, –4L — –3, –4, –4L — — —
EP3SL150
Commercial —
–2,–3, –4,
–4L
—
–2, –3, –4,
–4L
———
Industrial — –3, –4, –4L — –3, –4, –4L — — —
EP3SL200
Commercial — —
–2,–3, –4,
–4L
–2,–3, –4,
–4L
—
–2,–3, –4,
–4L
—
Industrial (1) — — –3, –4, –4L –3, –4, –4L — –3, –4, –4L —
EP3SL340
Commercial — — — — –2, –3, –4 –2, –3, –4 –2, –3, –4
Industrial (1) — — — — –3, –4, –4L –3, –4, –4L –3, –4, –4L
EP3SE50
Commercial
–2, –3, –4,
–4L
–2, –3, –4,
–4L
—————
Industrial –3, –4, –4L –3, –4, –4L — — — — —
EP3SE80
Commercial —
–2, –3, –4,
–4L
—
–2, –3, –4,
–4L
———
Industrial — –3, –4, –4L — –3, –4, –4L — — —
EP3SE110
Commercial —
–2,–3, –4,
–4L
—
–2, –3, –4,
–4L
———
Industrial — –3, –4, –4L — –3, –4, –4L — — —
