FMMT624
Document number: DS33110 Rev. 5 - 2
1 of 7
www.diodes.com
December 2012
© Diodes Incorporated
A
Product Line o
f
Diodes Incorporated
FMMT624
125V NPN LOW SATURATION TRANSISTOR IN SOT23
Features
• BV
CEO
> 125V
• I
C
= 1A high Continuous Collector Current
• I
CM
= 3A Peak Pulse Current
• R
CE(sat)
= 160mΩ for a low equivalent On-Resistance
• 625mW Power dissipation
• h
FE
specified up to 3A for high current gain hold up
• Totally Lead-Free & Fully RoHS compliant (Notes 1 & 2)
• Halogen and Antimony Free. “Green” Device (Note 3)
• Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
• Case: SOT23
• Case Material: molded plastic, “Green” molding compound
• UL Flammability Classification Rating 94V-0
• Moisture Sensitivity: Level 1 per J-STD-020
• Terminals: Finish – Matte Tin Plated Leads, Solderable per
MIL-STD-202, Method 208
• Weight 0.008 grams (approximate)
Applications
• DC-DC / DC-AC Modules
• Regulator
• LED driver
• CCFL Backlighting Inverters
Ordering Information (Note 4)
Product Marking Reel size (inches) Tape width (mm) Quantity per reel
FMMT624TA 624 7 8 3,000
FMMT624TC 624 13 8 10,000
Notes: 1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com for more information about Diodes Incorporated’s definitions of Halogen and Antimony free, "Green" and Lead-Free.
3. Halogen and Antimony free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl)
and <1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com.
Marking Information
624 = Product Type Marking Code
SOT23
Top View
Pin-Out
Top View Device Symbol
C
E
B
C
E
B
624
