Material group Materials
CAS-Nr.
if applicable
Average
mass
[%]*
Sum
[%]
Traces Comment
inorganic material silicon 7440-21-3 1 1
non noble metal copper 7440-50-8 20,4
inorganic material aluminium oxid 1344-28-1 6,6
non noble metal tin 7440-31-5 0,9
noble metal silver 7440-22-4 0,9
non noble metal magnesium 7439-95-4 X
non noble metal cobalt 7440-48-4 X
non noble metal aluminium 7429-90-5 1 1
polymers silicone gel 14,4 14,4
polymers PBT 27,6
inorganic material antimonytrioxide 1309-64-4 2,9
plastics brominated resin 2
plastics chlorinated resin 1,4
inorganic material silicondioxide / glasfiber 15,1
ferrous metal X12CrNi17-7(1.4310) 2,7
non noble metal tin 7440-31-5 X
non noble metal copper 7440-50-8 3,1
non noble metal zinc 7440-66-6 X
non noble metal nickel 7440-02-0 X
inorganic material lead oxide 1317-36-8 0,1 RoHS compliant
non noble metal copper 7440-50-8 X
non noble metal tin 7440-31-5 X
noble metal silver 7440-22-4 X
<25% 100
41,0 g
<25%
Company
Address
Internet
Material Content Data Sheet
Umbrella Spec
Easy2 B-Series
Date
2015-02-06
RoHS compliant
Yes
Revision
3.1
Construction element
chip
substrate including
metallisation
28,8
wire
encapsulation
housing
49
clamp
5,8
lead, finish and plating
SMD (including thermistors,
resistors and shunts)
deviation
Sum in total
Weight range of product family
**
81726 München
www.infineon.com
Fluctuation margin
*) related to component weight
**) Weight of particular product, see technical product information
Important Remarks:
1) This document provides full declaration of all materials present in Infineon products above a threshold
of 0,1 % b.w. (1000 ppm).
2) Trace concentrations (i.e. < 0,1 % b.w) present in products are marked with an "X" as far as they
represent substances-of-concern.
A list of substances-of-concern can be found at http://www.infineon.com/soc.
3) All statements are based on our present knowledge and are subject to change at any time due to
technical requirements and development.
Infineon Technologies
AG
