FT232HQ-TRAY 其他数据使用手册 - FTDI Chip（飞特帝亚）

FTDI  FT232RL-REEL  接口桥接器, USB 到 UART, 1.8 V, 5.25 V, SSOP, 28 引脚, -40 °C

FT232R - USB to Serial UART with Clock Generator, FTDI ChipThe FTDI Chip FT232R is a USB to serial UART interface with optional clock generator output. Asynchronous and synchronous bit bang interface modes are also available. Together with EEPROM, clock circuit and USB resistors effectively makes it a "3 in 1" chip for some applications. The internally generated clock (6 MHz, 12 MHz, 24 MHz, and 48 MHz) can be used to drive a microcontroller or external logic. The FT232R is available in compact 28-pin SSOP (RS 406-580) and 32-pin QFN (RS 730-0168) packages.\- Single chip USB to asynchronous serial data transfer interface. \- Entire USB protocol handled on the chip. No USB-specific firmware programming required. \- Fully integrated 1024-bit EEPROM storing device descriptors and CBUS I/O configuration. \- Fully integrated USB termination resistors. \- Fully integrated clock generation with no external crystal required plus optional clock output \- Data transfer rates from 300 Baud to 3 MBaud (RS422, RS485, RS232) at TTL levels. \- 128 B receive buffer and 256 B transmit buffer utilising buffer smoothing technology to allow for high data throughput ### 串行输入/输出外设

FTDI  FT232HL-REEL  接口桥接器, USB 至 UART, FIFO, 2.97 V, 3.63 V, LQFP, 48 引脚, -40 °C

FT232R - USB to Serial UART with Clock Generator, FTDI Chip The FTDI Chip FT232R is a USB to serial UART interface with optional clock generator output. Asynchronous and synchronous bit bang interface modes are also available. Together with EEPROM, clock circuit and USB resistors effectively makes it a "3 in 1" chip for some applications. The internally generated clock (6 MHz, 12 MHz, 24 MHz, and 48 MHz) can be used to drive a microcontroller or external logic. The FT232R is available in compact 28-pin SSOP (RS 406-580 - Single chip USB to asynchronous serial data

FT232B - USB to Serial UART, FTDI Chip FTDI Chip recommends using the FT323R (RS 406-580 - TTL data rate 300 Baud to 3 MBaud \- RS232 data rate 300 Baud to 3 MBaud \- RS422/RS485 data rate 300 Baud to 3 MBaud \- 384 Byte Receive buffer/128 Byte Transmit buffer for high data throughput \- Full hardware assisted or X-On/X-Off handshaking \- Support for event characters and line break condition \- Auto transmit buffer control for RS485 \- Compact 32-pin (7 x 7 mm) LQFP package \- Integrated 6 MHz - 48 MHz clock multiplier \- Integrated 3.3 V regulator - no external regulator required \- 4.4 V to 5.25 V single supply operation \- UHCI/OHCI compliant 串行输入/输出外设

USB 全速 转 串行 UART IC - LQFP-32

FTDI  FT232RQ  接口桥接器, USB 到 UART, 1.8 V, 5.25 V, QFN, 32 引脚, -40 °C

FTDI  FT232HQ-REEL  接口桥接器, USB 至 UART, FIFO, 2.97 V, 3.63 V, QFN, 48 引脚, -40 °C
