Finisar Corporation - April 2015 Rev. A1 Page 1
Product Specification
Extended Temperature 10Gb/s 850nm SFP+ Datacom Transceiver
FTLX8574D3BNL
PRODUCT FEATURES
• Hot-pluggable SFP+ footprint
• Supports 9.95 to 10.5 Gb/s bit
rates*
• Power dissipation < 1W
• RoHS-6 compliant (lead-free)
• Commercial temperature range
-5°C to 85°C
• Single 3.3Vpower supply
• Maximum link length of 400m on
OM4 MMF
• Uncooled 850nm VCSEL laser
• Receiver limiting electrical
interface
• Duplex LC connector
• Built-in digital diagnostic functions
APPLICATIONS
• 10GBASE-SR/SW 10G Ethernet
• 1200-Mx-SN-I 10G Fibre Channel
Finisar’s FTLX8574D3BNL Extended Temperature 10Gb/s SFP+ transceivers are
designed for use in 10-Gigabit Ethernet links over multimode fiber. They are compliant
with SFF-8431
1
, SFF-8432
2
, IEEE 802.3-2012 10GBASE-SR/SW
3
and 10G Fibre
Channel 1200-Mx-SN-I
4
. Digital diagnostics functions are available via a 2-wire serial
interface, as specified in SFF-8472
5
. The FTLX8574D3BNL is a “limiting module”, i.e.,
it employs a limiting receiver. Host board designers using an EDC PHY IC should
follow the IC manufacturer’s recommended settings for interoperating the host-board
EDC PHY with a limiting receiver SFP+ module. The optical transceiver is compliant per
the RoHS Directive 2011/65/EU
6
. See Finisar Application Note AN-2038
7
for more
details.
PRODUCT SELECTION
FTLX8574D3BNL
*Contact Finisar for higher data-rate support up to 11.1Gbps.
