R
DC COMPONENTS CO., LTD.
RATING AND CHARACTERISTIC CURVES (GBPC35005 THRU GBPC3510)
Single Phase Half Wave
60Hz Inductive or
Resistive Load
CASE TEMPERATURE, (
o
C)
0
50 100 150
FIG. 2 - TYPICAL FORWARD CURRENT DERATING CURVE
50
40
30
20
10
AVERAGE FORWARD OUTPUT CURRENT, (A)
FIG. 1 - MAXIMUM NON-REPETITIVE FORWARD SURGE CURRENT
PEAK FORWARD SURGE CURRENT, (A)
NUMBER OF CYCLES AT 60Hz
1 2 5 10 20 50 100
0
500
200
400
100
8.3ms Single Half Sine-Wave
(JEDEC Mathod)
300
INSTANTANEOUS FORWARD VOLTAGE, (V)
.6 .7 .8 .9 1.0 1.3
Pulse Width=300ms
1% Duty Cycle
FIG. 3 - TYPICAL INSTANTANEOUS FORWARD CHARACTERISTICS
100
10
1
.1
1.21.1
INSTANTANEOUS FORWARD CURRENT, (A)
TJ=25
o
C
PERCENT OF RATED PEAK REVERSE VOLTAGE, (%)
0 20 40 60 80 100 120 140
FIG. 4 - TYPICAL REVERSE CHARACTERISTICS
10
1.0
.1
.01
INSTANTANEOUS REVERSE CURRENT, (µA)
TJ=25
o
C
REV-1,Apr/25/2013
