Page 1Product Page
10/20/2010 4:54:30 PMhttp://sensing.honeywell.com/index.cfm?ci_id=140301&la_id=1&pr_id=87866
find out more
Click here to contact us
Search
Products
Controls Monitoring and
Lighting (352)
Machine Safety (1701)
Sensors (6224)
Switches (9749)
Wireless (21)
Technology
Electromechanical (9301)
Flexible Heaters (140)
Microstructure (1486)
Optical/Infrared (1042)
Thick Film (1764)
More...
new products
New Wireless Products
Go farther. Work smarter. Explore new
possibilities. Just by cuttingthe cordand
making the switch.
Wireless Web Site
WGLA and WPMM
XYR6000™
white papers
Wireless Switches Offer Unlimited
Benefit
BasicSwitches Are Not Created
Equal
ApplyingPrecision Switches
Sensors for MedicalDevices
New Ways to Measure Torque
Choosing Safety Switches
Specifying Hour Meters
Need help?
GLAA01A1A
( Home : Products : MICRO SWITCH™ Global
Limit
Switches» GLSDIN» Switches» MICROSWITCH™Limit
Switches )
Global Limit Switches Series GLS: Side Rotary With Roller - Standard,
1NC 1NO SPDT SnapAction, 0.5in - 14NPT conduit
A
ct
ua
l
pr
od
uc
t
ap
pe
ar
a
nc
e
m
ay
va
ry
.
Overview Specs Documentation Application Notes
contacts
Customer Service
Technical Support
Global Sales & Service
View Site Demo
Site Comments?
meet dr. larry
VIDEO -
Dr. Larry
Goldstein explains our
newest and best
technologies.
Meet Dr.Larry
my links
Loginto iCOM
Loginto Rep/AD Portal
Loginto Digital University
News Center
HONEYWELL ANNOUNCES
ADDITION TO RELIALIGN™
RESIDENTIALDOOR
INTERLOCK SWITCHES THAT
FEATURE RUGGED, PLASTIC
HOUSING
HONEYWELL RELEASES
UNLIMITED POTENTIAL WITH
NEW LIMITLESS™ WIRELESS
SWITCHES
HONEYWELL’S XYR6000
WIRELESS POSITION SENSOR
ENABLES MONITORING IN
HAZARDOUS AREAS AND
REMOTE LOCATIONS
MICRO SWITCH
Anniversary site
Product Specifications
Availability Global
Operating Force (OF) 0,330 N m [2.90 in lb]
Pretravel (PT) 26°
Overtravel (OT) 59°
Differential Travel (DT) 12° max.
Product Type EN50041/47 Global Limit Switch
Actuator Side Rotary
Lever Type Roller - Standard
Circuitry 1NC 1NO SPDT SnapAction
Ampere Rating 10 A (Thermal)
SupplyVoltage 600 Vac and 250 Vdc max.
Housing Material Zinc Die-Cast
Termination Type 0.5 in - 14NPT Conduit
Housing Type EN 50041
Series Name GLS DIN
Shock 50 gper IEC 68-2-27c (w/o Actuator)
Vibration 10 gper IEC 68-2-6(w/o Actuator)
Sealing IP67;NEMA 1, 4, 12, 13
UL File # E37138 & E157416
Expected MechanicalLife 15 Million
Operating Temperature -25 °C to 85 °C [-13 °F to 185 °F]
Comment Roller Material: Plastic
Agency Approvalsand
Standards
UL, CE, CSA, CCC. IEC 947-5-1, EN60947-5-1, UL508
UNSPSC Code 302119
UNSPSC Commodity 302119 Switches and controls and relays
Sealed Industrial
Operating Position (OP) 26°
