Explanation of Symbols in This Catalog
For applications that do not require a particular
reliability. such as general equipment.
Powertrain/Safety for Automotive
Products use for applications (running, turning,
stopping, and safety devices) that particularly concern
human life, such as in devices for automotive.
Infotainment for Automotive
The product for entertainment equipment like car
navigations, car audios, and body control equipment
like wipers, power windows.
Medical-grade products for Implanted Medical Devices
These products are intended for use in implanted
medical devices such as cardiac pacemakers, cochlear
implants, insulin pumps, and gastric electrostimulators.
They are suitable for use in non-critical circuits.
*1
*1
Non-critical circuits
This term refers to circuits in implanted medical
devices that are not directly linked to life support, i.e.
circuits that will not directly endanger the life of the
patient should the functionality of the device be
reduced or halted by failure of the circuit.
AEC-Q200 compliant product
Low-inductance product suitable for noise suppression.
This product has extremely low ESL and is suitable for
suppression of noise, including high frequencies.
This product can also be used as a low-ESL,
high-performance bypass capacitor.
Product for bonding
Since gold is used for the external electrodes, the
capacitor can be mounted by die bonding/wire bonding.
Derating 1
This product is suitable when a voltage continuously
applied to a capacitor in an operating circuit, is used
below (derated) the rated voltage of the capacitor. This
model guarantees the test conditions in the endurance
test, at a rated voltage x 100% at the maximum
operating temperature. A reliability assurance level
equivalent to a common product can be secured, by
using this product within the voltage and temperature
derated conditions recommended in the figure below.
Derating 2
When the product temperature exceeds 105°C, please
use this product within the voltage and temperature
derated conditions in the figure below.
Derating 3
Please apply the derating curve according to the
operating temperature.
Please refer to detailed specifications sheet for details.
Safety Standard Certified Product
Products that acquired safety standard certification
IEC60384-14 and products based on the Electrical
Appliance and Material Safety Law of Japan.
Low dissipation for high frequency
By devising ceramic materials and electrode materials,
low dissipation is achieved in frequency bands of VHF,
UHF, and microwave or beyond.
Low inductance
This capacitor is designed so that the parasitic
inductance component (ESL) that the capacitor has on
the high frequency side becomes lower.
Product suitable for acoustic noise reduction and low
distortion
This product suppresses acoustic noise, which occurs
when a ceramic capacitor is used, by devising the
materials and configuration.
Links are provided to the latest information from the PDF version of the catalog, which is available on the web.
Fail safe product
This capacitor is designed to prevent failures as much
as possible by short mode.
Product resistant to deflection cracking
This capacitor is designed to prevent failures as much
as possible by short mode caused by cracking when
there is board deflection.
Product with solder cracking suppression
This capacitor is configured with metal terminals and
leads connected to the chip. The metal terminals and
leads relieve the stress from expansion and contraction
of the solder, to suppress solder cracking.
No DC bias characteristics
Polymer capacitor is no capacitance change with DC bias
due to aluminum oxidized film for dielectric.
Recommended Conditions of the Derating Operating Voltage and Temperature
0255075100125150
0
20
40
60
80
100
120
Product Temperature (°C)
Operating Voltage/Rated Voltage (%)
125°C Type
105°C Type
85°C Type
0255075100125150
0
Product Temperature (°C)
Rated Voltage (%)
400
500
100
200
300
600
700
Rated Voltage 630V
Rated Voltage 450V
(350V)
(450V)
WEB
C02E.pdf
Dec.7,2016
!
Note
• Please read rating and
!
CAUTION (for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
