GRM32RR71C475KA01L 产品手册 - muRata（村田）
制造商:
muRata（村田）
分类:
陶瓷电容
封装:
1210
描述:
MURATA GRM32RR71C475KA01L 多层陶瓷电容器, 表面贴装, GRM系列, 4.7 µF, ± 10%, X7R, 16 V, 1210 [3225 公制]
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
封装尺寸在P172
型号编码规则在P4
封装信息在P6P34P180
焊接温度在P167P176P177
技术参数、封装参数在P34P35P105P127P129P132P141P143P146P149P151P153
应用领域在P34P35P105P127P129P132P141P143P146P149P151P153
导航目录
GRM32RR71C475KA01L数据手册
Page:
of 186 Go
若手册格式错乱，请下载阅览PDF原文件
!
Note
• Please read rating and
!
CAUTION (for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifi cations. Therefore, please approve our product specifi cations or transact the approval sheet for product specifi cations before ordering.
Explanation of Symbols in This Catalog
L x W dimension: products of 0.6 x 0.3 mm or less
Low dissipation for high frequency
By devising ceramic materials and electrode materials,
low dissipation is achieved in frequency bands of VHF,
UHF and microwave or beyond.
Low inductance
This capacitor is designed so that
the parasitic inductance component (ESL)
that the capacitor has on the high frequency
side becomes lower.
Product suitable for acoustic noise reduction and low distortion
This product suppresses acoustic noise,
which occurs when a ceramic capacitor is used,
by devising the materials and configuration.
Product resistant to deflection cracking
This capacitor is designed to prevent failures as much
as possible by short mode caused by cracking
when there is board deflection.
Product with solder cracking suppression
This capacitor is configured with metal terminals
and leads connected to the chip.
The metal terminals and leads relieve the stress from expansion
and contraction of the solder, to suppress solder cracking.
Voltage and temperature derating recommended product
This product is suitable when a voltage continuously applied
to a capacitor in an operating circuit, is used below (derated)
the rated voltage of the capacitor.
This model guarantees the test conditions in the endurance test,
at a rated voltage x 100% at the maximum operating temperature.
A reliability assurance level equivalent to a common product
can be secured, by using this product within the voltage and
temperature derated conditions recommended in the figure below.
s
Recommended Conditions of the Derating Operating Voltage and Temperature
0255075100125150
0
20
40
60
80
100
120
Operating Voltage/Rated Voltage (%)
Product Temperature (°C)
125°C Type
105°C Type
85°C Type
EU RoHS
Compliant
s
All the products in this catalog comply with EU RoHS.
s
EU RoHS is "the European Directive 2011/65/EU on the Restriction of the Use
of Certain Hazardous Substances in Electrical and Electronic Equipment."
s
For more details, please refer to our website 'Murata's Approach for EU RoHS'
(http://www.murata.com/info/rohs.html).
