THIS FORM PAGE IS TO BE REVISED BY THE NORTHBROOK LABEL DEPARTMENT ONLY
Recognized Component Marking Data Page (RCMDP)
(FILE IMMEDIATELY AFTER AUTHORIZATION PAGE)
RECOGNIZED COMPONENT MARKING
Products Recognized under UL’s Component Recognition Service are identified
by marking elements consisting of:
1. The Recognized Company’s identification specified in this
document.
2. A catalog, model or other applicable product designation
specified in the descriptive sections of this document.
3. The UL Recognized Component Mark shown below:
(A) Recognized only to Canadian safety requirements, or;
(B) Recognized to both U.S. and Canadian safety requirements.
Only those components, which actually bear the Marking, should be considered
as being covered under the Recognition Program. The UL Listing or
Classification Mark is not authorized for use on or in connection with
Recognized Components.
Recognized Component Mark
Minimum size of the Recognized Component Mark is not specified as long as it
is legible. Minimum height of the registered symbol ® shall be 3/64 inch but
may be omitted if it is out of proportion to the Recognized Component Mark or
not legible to the naked eye.
The manufacturer may reproduce the Mark electronically. Any decision
regarding the acceptability of the manufacturer’s Mark reproduction will be
made at the Reviewing Office.
Created by UL Document Assembler 2016-09-13 21:50:29 -05:00
