For price, delivery and to place orders: Hittite Microwave Corporation, 2 Elizabeth Drive, Chelmsford, MA 01824
Phone: 978-250-3343 Fax: 978-250-3373 Order On-line at www.hittite.com
Application Support: Phone: 978-250-3343 or apps@hittite.com
SWITCHES - SPST - SMT
3
HMC550A / 550AE
v00.1212
GaAs MMIC SPST
FAILSAFE SWITCH, DC - 6 GHz
Insertion Loss, Power Off Return Loss, Power Off
Conditions Vdd - Vctl ≥ + 1.2 Vdc -0.2 Vdc < Vdd - Vctl < +0.4 Vdc
RF1 - RF2 OFF ON
Vdd (V) 0 (Unpowered) 1.6 2.2 3.3 5.0
Vctl (V) 0 (Unpowered) 0 > 1.2 < 1.0 > 1.8 < 2.1 > 2.9 < 3.8 > 4.6
RF1 - RF2 ON OFF ON OFF ON OFF ON OFF ON
Operating Conditions
Vdd & Vctl = 0 Vdc to +5 Vdc; Vctl_max = Vdd + 0.2 Vdc; Idd & Ictl = 0.1 µA, Typical
Examples of Typical Operating Conditions - Idd & Ictl = 0.1 µA, Typical
-2.5
-2
-1.5
-1
-0.5
0
012345678
INSERTION LOSS (dB)
FREQUENCY (GHz)
-30
-25
-20
-15
-10
-5
0
012345678
RETURN LOSS (dB)
FREQUENCY (GHz)
0
5
10
15
20
25
30
35
40
0123456
INPUT P0.1dB (dBm)
FREQUENCY (GHz)
Input P0.1dB, Power Off
30
35
40
45
50
55
60
0123456
INPUT IP3 (dBm)
FREQUENCY (GHz)
Input IP3, Power Off
